Lukas LKE 55 - Manual (Page 15)

15
15.2 Central bolt / Tightening torque
15.3 Noise emission
15.4 Others
Type LKE 50 / LKE 51 LKE 70 LKE 55
Central bolt M 24 x 1.5 (SW 36)
Torque Nm 100+10 120+10 110+10
Type LKE 50 LKE 51 LKE 70 LKE 55
Following the regulations No load 65 dB 63 dB 68 dB Measuring
of EN ISO 3744 Full load 69 dB 67 dB 70 dB distance 1.0 m
LKE 50 / 51 / 70 LKE 55
Temperature ranges °C °C
Ambient temperature (when charging the accu) + 5 ... + 40 0 ... +45
In exceptional cases (with decreased accu life time) + 5 ... + 50 --
Ambient temperature (during rescue operation) - 20 ... + 60
Storage temperature (device not in operation) - 30 ... + 60
LKE_84150_7060_Ag0206_e.P65 subject to revision
© Copyright 2003 LUKAS Hydraulik GmbH
LUKAS Hydraulik GmbH
A Unit of IDEX Corporation
Weinstraße 39, 91058 Erlangen
Postfach 2560, 91013 Erlangen • Germany
Tel.: + 49 (0) 9131 / 698-0
Fax + 49 (0) 9131 / 69 83 94
Internet: http://www.lukas.de
e-mail: [email protected]
