Electrical mounting panel - fuses, relays & buzzer – Lull 644B Parts Manual User Manual
Page 635

ITEM
PART NO.
DESCRIPTION
QTY.
ITEM
PART NO.
DESCRIPTION
QTY.
1
38212B
1
Mounting Panel, Electrical Components
2
P01400
11
Flatwasher, #10
3
P01306
15
Lockwasher, #10
4
P02054
11
Screw, Slotted Rd. Hd., #10-24 × 1/2"
5
P27307
1
Buzzer, Brake Pressure Warning
6
P13709
1
Relay, Horn
7
36445A
2
Fuse Panel, 6 Circuit
8
36496A
1
Fuse, Blade Type - 7.5 Amp
P30797
3
Fuse, Blade Type - 10 Amp
P30798
1
Fuse, Blade Type - 15 Amp
P30799
1
Fuse, Blade Type - 20 Amp
9
P02059
4
Screw, Slotted Rd. Hd., #10-24 × 1"
10
P27803
1
Terminal Adapter Tab, Male Push-on
11
P01402
7
Flatwasher, 1/4"
12
P01308
4
Lockwasher, 1/4"
13
P00003
1
Capscrew, Hx., 1/4"-20 × 3/4"
14
38327A
3
Stand-off, 3 1/4" Long Hex
38328A
-
Stand-off, 2 3/4" Long Hex
15
38251A
3
Thumb Screw, 1/4"-20
16
38319B
1
Cover, Electrical Panel
17
38071D
1
Wire Harness, Relay (Includes Items 18-23)
18
P21787
3
Diode Module
19
P30796
1
Relay, S.P.D.T., Oscillation Lock Lamp
20
P30796
1
Relay, S.P.D.T., Oscillation Lock
21
P30796
1
Relay, S.P.D.T., Oscillation Lock
22
P30423
1
Relay, S.P.S.T., Back-Up Alarm
23
P30423
1
Relay, S.P.S.T., Neutral Start
ELECTRICAL MOUNTING PANEL - FUSES, RELAYS & BUZZER
9.2.1
1044C-42 S/N 101–116
1044C-54 S/N 101–154
644B-42 S/N 101–207
644B-37 S/N 101–590 & 592-666
844C-42 S/N 101–621
10K-42 S/N 101–106
10K-54 S/N 101–103
8K-42 S/N 101–220
6K-42 S/N 101–119
6K-37 S/N 101–317
Rev. 004
