Lull 644B Parts Manual - Manual (Page 343)

ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY.
1 65668A 1 Pin, Lock Pivot Plate
2 P03865 3 Cotter Pin, 3/16" × 1 1/2"
3 P00420 1 Capscrew, Hx., 1/2"-13 × 7"
4 36863A 1 Pin, Quick Attach Pivot
5 P01312 2 Lockwasher, 1/2"
6 P01510 1 Nut, Hx., 1/2"-13
7 36013A A/R Shim -.036" (.91mm)
17012A A/R Shim -.075" (1.90mm)
8 65667A 1 Pin, Front Carriage Tilt - Rod End
9 34178A 1 Lock Pin
10 P00403 1 Capscrew, Hx., 1/2"-13 × 1 1/4"
11 37103X 1 Handle, Release
12 P01361 1 Starwasher, 1/2"
13 P01560 1 Jam Nut, Hx., 1/2"-13
14 37140X 1 Spring, Release
15 P01254 1 Flatwasher, 1/2" SAE - Hardened
16 ➋N.L.A. 1 Rod, Quick Attach Release
17 ➊N.L.A. 1 Quick Attach (Weldment Style)
18 P00209 1 Capscrew, Hx., 3/8"-16 × 2 1/4"
19 32493A 1 Lock Pin
20 P01310 1 Lockwasher, 3/8"
21 P01508 1 Nut, Hx., 3/8"-16
22 10236900 1 Lock Plate
23 P01411 2 Flatwasher, 1"
NOTES:
➊ For Replacement Order Quick Attach Conversion Kit 67487A.
Kit Includes: Cast Style Quick Attach, Release Rod & Spring, Rod Bracket
and Bracket Mounting Hardware. (See Page 4.11.1.2 for Breakdown)
➋ Order Rod Replacement Kit 67060A (Includes items 14&16).
(See Page 4.11.1.2 for Breakdown)
QUICK ATTACH GROUP ASSEMBLY (Weldment Type) 4.11.1
1044C-42 S/N 101–121
1044C-54 S/N 101–214
644B-42 S/N 101–240
644B-37 S/N 101–866
10K-42 S/N 101–107
10K-54 S/N 101–107 & 109
8K-42 S/N 101–261
6K-42 S/N 101–131
Rev. 005
844C-42 S/N 101–679 & 681-782
6K-37 S/N 101–391
644B
6K
844C
8K
1044C
10K
▼
