ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY.
1 ➊P31346
N.L.A.
2 Steer Cylinder Assembly - Left Front, Right Rear
18.61" (47.3mm) Long Retracted
(Includes Items 2–13)
➋P31347
N.L.A.
2 Steer Cylinder Assembly - Right Front, Left Rear
19.61" (49.8mm) Long Retracted
(Includes Items 2–13)
2 N.S.S. 1 Rod Wiper
3 N.S.S. 1 Rod Seal, U-Cup
4 P31548 1 Gland
5 N.S.S. 1 Lock Ring
6 N.S.S. 1 Gland Seal
7 P31348 1 Rod, Cylinder - 16.12" (40.9mm) Long
(for P31346)
P31349 1 Rod, Cylinder - 17.12" (43.5mm) Long
(for P31347)
8 N.S.S. 1 O-Ring
9 N.S.S. 1 Seal, Piston
10 P31549 1 Piston
11 N.S.S. 1 Wear Ring
12 N.S.S. 1 Nut
13 N.S.S. 1 Barrel
REF P31334 - Seal Kit (Includes Items 2, 3, 5, 6, 8, 9, 11)
NOTES:
➊ Service with 37433X. P31346 is No Longer Available. See Page 1.10.1.1.
➋ Service with 37434X. P31347 is No Longer Available. See Page 1.10.1.1.
N.S.S. = Not Sold Separately
STEER CYLINDER ASSEMBLY (PS 7036) 1.10.1
644B-42 S/N 101–133
844C-42 S/N 101–356, 425 & 426
6K-42 S/N 101–109
6K-37 S/N 101–236
8K-42 S/N 101–182
1044C-42 S/N 101–107
644B-37 S/N 101–462
Rev. 002
10K-42 S/N 101–106
644B
6K
844C
8K
1044C
10K
▼
