- 4 -
S
PECIFICATIONS
Specifications subject to change without notice
Compaction depth: Clean sand & optimum moisture.
MBW recommends that lifts not exceed 12” (31 cm)
GPR65 GPR68 GPR77
Centrifugal Force 6000 lbf (27 kN) 7775 lbf (34 kN)
Exciter vpm 4400 vpm 4700 vpm
Width & Length
15 in x 26.3 in
(381mm x 668mm)
18 in x 26.3 in
(457 mm x 668 mm)
22 in x 26.3 in
(559 mm x 668 mm)
Travel Speed 92 ft./min. (28 m/min.) 88 ft./min. (27 m/min.) 86 ft./min. (26 m/min.)
Compaction Depth Up to 22 in (56 cm) See Note Below
Compaction Area 6900 sq. ft./hr (640 sq. m/hr) 7920 sq. ft./hr (736 sq. m/hr) 9460 sq. ft./hr (879 sq. m/hr)
Operating Weight
Honda - 325 lbs (147 kg)
Hatz-365 lbs (165 kg)
Honda - 330 lbs (150 kg)
Robin - 330lbs (150 kg)
Hatz- 370 lbs (168 kg)
Honda - 397 lbs (180 kg)
Hatz- 399 lbs (181 kg)
Engine Speed
Honda 3400 RPM
Hatz 3600 RPM
Engine
Honda GX160
Hatz 1B20
Honda GX160
Hatz 1B20
ROBIN EX17
Honda GX270
Hatz 1B20
