MBW GPR77 - Manual (Page 28)

- 25 -
ITEM PART NO. DESCRIPTION GPR65 GPR68 GPR77
1. 00808 KEY, 1/4” SQUARE x 1-3/4” LG. 1
2. 01182 V-BELT, (A-34) 1 1
05831 V-BELT, (A-35) 1
3. 06747 SCS, M8 X 25MM 1 1
F072010FSS FSS, 7/16-20 X 1-1/4 1
4. 14429 ROD END, 1/4-28 RH 1 1 1
5. 16523 FITTING, PLUG, HYDRAULIC 1 1 1
6. 16544 WASHER, COUNTERSUNK 1
7. 16578 FITTING, ADAPTOR, HYDRAULIC 1 1 1
8. 16852 ENGINE DECK 1 1
19105 ENGINE DECK 1
9. 16859 ROLLCAGE, COATED 1 1
19119 ROLLCAGE, COATED 1
10. 16862 BELTGAURD 1 1 1
11. 16849 BASEPLATE, GPR 65 1
16992 BASEPLATE, GPR 68 1
19101 BASEPLATE, GPR 77 1
12. 17006 EXCITER, CAST IRON 1 1
19108 EXCITER, CAST IRON 1
13. 17064 HATZ, DIESEL 1 1
19129 HATZ, DIESEL, 1” STRAIGHT SHAFT 1
14. 17065 CLUTCH, TAPER SHAFT 1 1
19127 CLUTCH, STRAIGHT SHAFT 1
15. 17117 SHOCKMOUNT, 2.95 OD X 2.17 LONG 4 4 4
16. 18087 HOSE, 1/2 X 8.75 1 1 1
17. 18094 PLATE, GAURD, ENGINE, 1B20 1 1
19124 EXTENSION, BELT GAURD 1
18. 18110 SHIFTER CABLE ASM AND SLEEVE (Order 18109 for sleeve only) 1 1
19. 19136 SPACER, CLUTCH, 1-3/8 OD x 5/8 LG. 1
20. F042006FWS FWLS, 1/4-20 X 3/4 ZP 4 4 4
21. F042006HCS HHCS, 1/4-20 X 3/4 GR5 ZP 1 1 1
22. F0420HN NUT, HEX 1/4-20 ZP 1 1 1
23. F0428HN NUT, HEX 1/4-28 ZP 1 1 1
24. F051808HCS HHCS, 5/16-18 X 1 GR5 ZP 4 4 4
25. F05LW LOCKWASHER, 5/16 ZP 4 4 4
26. F05SW WASHER, 5/16 X 3/4 X 15ga ZP 4 4 4
27. F061608FWS FWLS, 3/8-16 X 1 4 4 4
28. F0616FN FLANGE WHIZ-LOCK NUT, 3/8-16 4 4
29. F06LW LOCKWASHER, 3/8 ZP 1 1
30. F06SW WASHER, 25/64 X 1 X 1/8 ZP 1 1
31. F071420FSS FSS, 7/16-14 X 2-1/2” 6 6
32. F0714HN NUT, HEX 7/16-14 ZP 6 6
33. F07LW LOCKWASHER, 7/16 ZP 6 6
34. F081307HCS HHCS, 1/2-13 X 7/8 GR5 ZP 4 4
35. F0813HN NUT, HEX, 1/2-13, ZP 4 4 4
36. F08LW LOCKWASHER, 1/2 ZP 4 4 8
37. F08SW WASHER, 9/16 X 1-3/8 X 12ga ZP 4 4 4
38. M10C016FWS FWS, M10 X 16 2 2
M08C016FWS FWS, M8 X 16 4
14477 SHIFTER, NO CABLE
19511 SHIFT HANDLE LEVER ONLY
20414 KIT, SHIFT CABLE
H50426000 AIR FILTER HATZ DIESEL 1B20 & 1B30 (NOT SHOWN)
01635210 FUEL FILTER HATZ DIESEL (NOT SHOWN)
