Installing the replacement front bezel – Apple Xserve (Early 2008) DIY Procedure for Front Bezel User Manual
Page 4
Xserve (Early 2008) Front Bezel Replacement Instructions
4
Installing the Replacement Front Bezel
Leave the power button and system identifier button on the server, but note that the
1.
button(s) could be loose. To prevent damage to the buttons, be sure to align the buttons
with the front panel openings as you install a replacement front bezel.
Make sure the light pipe is secure in the front bezel. If it comes out, align the pins to the
2.
front bezel, and insert it into the slot in the front bezel.
Place the front bezel on the server, carefully matching openings with buttons and ports.
3.
