Hornady New Dimension Custom Grade Dies - Manual (Page 8)

Key Description Part No.
A Zip Spindle Lock 398731
B Size Die Body *
C Zip Spindle 398567
D Headed Decap Pin 390222
E Expander *
Decap Retainer
F Seater Adjustment 044100
Screw
G Seater Lock Nut 044800
H Washer 398067
DIE SET
PARTS LIST
Key Description Part No.
I Seater Die Body *
J Retaining Ring 396430
K Seating Stem *
L Alignment Sleeve *
M Expander Die Body *
(3 Die only)
N Lock Ring Screw 390200
O Sure-Loc Lock Ring 044000
P Allen Wrench 390656
*Caliber specific part numbers are assigned to these items.
