Hornady Lock-N-Load Ammo Plant - Manual (Page 52)

Rifle Dies & Reloading Essentials
(Reference Chart)
Rifle
Cartridge
Bu
lle
t D
ia
m
et
er
(in
ch
es)
Di
e S
et
Die
S
er
ie
s
Fu
ll-L
en
gt
h
Si
ze D
ie
Se
at
in
g Di
e
Ex
pa
nde
r D
ie
Tap
er
C
rim
p
Di
e O
nl
y
N
ec
k S
iz
e D
ie
She
ll H
ol
de
r
# / I
te
m N
o.
Sh
el
l P
la
te
# / I
te
m N
o.
Ca
se
Fee
de
r P
la
te
Si
ze / I
te
m N
o.
Bul
le
t
Fe
ed
er D
ie
Tr
im
m
er
P
ilo
t
# / I
te
m N
o.
Pr
im
er
P
un
ch
Bul
le
t
Pu
lle
r C
oll
et
# / I
te
m N
o.
6.5 REM MAG .264 546294 IV — — — — 046043 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #5 / 390947 Large #4 / 392157
264 WIN MAG .264 546278 III 046279 044123 — — 046043 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #5 / 390947 Large #4 / 392157
6.5x68 .264 546286 III 046287 044123 — — 046043 #30 / 390570 #30 / 392630 Lg Rfl / 095316 — #5 / 390947 Large #4 / 392157
6.5 CARC .268 546288 III 046289 044134 — — 046043 #21 / 390561 — / — Lg Rfl / 095316 — #5 / 390947 Large #4 / 392157
6.8MM REM SPC .277 546299 III 046711 044713 — — — #12 / 390552 #12 / 392612 Lg Rfl / 095316 — #6 / 390948 Small #5 / 392158
270 REN .277 — — — — — — — #3 / 390543 #3 / 392603 Sm Rfl / 095314 — #6 / 390948 Small #5 / 392158
270 WIN .277 546300 I 046301 044107 — — 046051 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #6 / 390948 Large #5 / 392158
270 WIN SHORT MAG .277 546297 I 046450 044161 — — 046055 #35 / 390575 #35 / 392635 Lg Rfl / 095316 — #6 / 390948 Large #5 / 392158
270 WBY .277 546298 III 046299 044107 — — 046051 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #6 / 390948 Large #5 / 392158
7MM/223 INGRAM .284 546318 IV — — — — 046049 #16 / 390556 #16 / 392616 Sm Rfl / 095314 — #7 / 390949 Small #6 / 392159
7MM TCU .284 546328 IV — — — — 046049 #16 / 390556 #16 / 392616 Sm Rfl / 095314 — #7 / 390949 Small #6 / 392159
7x47 HELM .284 546306 IV — — — — 046049 #16 / 390556 #16 / 392616 Sm Rfl / 095314 — #7 / 390949 Large #6 / 392159
7MM REM BR .284 546324 IV — — — — 046049 #1 / 390541 #1 / 392601 Sm Rfl / 095314 — #7 / 390949 Large #6 / 392159
7x30 WATERS .284 546304 IV — — — — 046049 #2 / 390542 #2 / 392602 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM MERRILL .284 546322 IV — — — — 046044 #4 / 390544 #4 / 392604 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM/08 REM .284 546316 I 046317 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7x57-7MM MAUSER .284 546308 I 046309 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7x57R .284 — — — — — — 046044 #13 / 390553 #13 / 392613 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
284 WIN .284 546302 III 046303 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
280 REM/7MM EXP .284 546320 I 046321 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
280 ACKLEY IMP .284 546321 III 046304 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7x65R .284 546314 III 046315 044133 — — 046044 #13 / 390553 #13 / 392613 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7x61 S&H .284 546310 IV — — — — 046044 #35 / 390575 #35 / 392635 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7x64 .284 546312 III 046313 044108 — — 046044 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM REM SA ULTRA MAG .284 546309 III 046452 044108 — — 046056 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM REM MAG .284 546326 I 046327 044108 — — 046044 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM WIN SHORT MAG .284 546327 I 046451 044108 — — 046056 #35 / 390575 #35 / 392635 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM WBY .284 546330 III 046331 044108 — — 046044 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM STW .284 546440 IV — — — — 046044 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7MM REM ULTRA MAG .284 546307 III 046454 044133 — — 046056 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #7 / 390949 Large #6 / 392159
7.35 CARC .300 546332 IV — — — — — #21 / 390561 — / — Lg Rfl / 095316 — #8 / 390950 Large #7 / 392160
30 M1 CARB .308 546503 II 046504 044142 044505 — — #22 / 390562 #22 / 392622 Sm Rfl / 095314 — #9 / 390951 Small #7 / 392160
30 REM .308 — — — — — — 046050 #12 / 390552 #12 / 392612 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 AAC/WHISPER .308 546349 I 046459 044165 — — — #16 / 390556 #16 / 392616 Sm Rfl / 095314 — #9 / 390951 Small #7 / 392160
30 HERRETT .308 546334 IV — — — — 046050 #2 / 390542 #2 / 392602 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30/30 WIN .308 546342 I 046343 044111 — — 046050 #2 / 390542 #2 / 392602 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30-30 ACKLEY IMP .308 546345 IV — — — — 046050 #2 / 390542 #2 / 392602 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
303 SAV .308 546354 IV — — — — 046050 #33 / 390573 — / — Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 SAV .308 546348 III 046349 044111 — — 046050 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30 MERRILL .308 546338 IV — — — — 046050 #4 / 390544 #4 / 392604 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
308 MARLIN EXP .308 546357 I 046358 044111 — — 046045 #27 / 390567 #27 / 392627 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
7.5 SWISS (7.5X55) .308 546360 III 046361 044111 — — 046045 #2 / 390542 #2 / 392602 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
7.5 SWISS K31 .308 546361 III 046362 044111 — — 046045 #2 / 390604 — / — Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
308 WIN .308 546358 I 046359 044111 — — 046045 #1 / 390541 #1 / 392601 Lg Rfl / 095316 095345 #9 / 390951 Large #7 / 392160
308 WIN MATCH .308 — — 544359 — — — 544357 #1 / 390541 #1 / 392601 Lg Rfl / 095316 095345 #9 / 390951 Large #7 / 392160
7.62 RUSS .308 546362 III 046363 044111 — — 046050 #23 / 390563 #23 / 392623 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30/40 KRAG .308 546344 IV — — — — 046045 #11 / 390551 #11 / 392611 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30 TC .308 546335 I 046336 044111 — — 046045 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30/06 .308 546340 I 046341 044112 — — 046045 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30/06 ACKLEY IMP .308 546341 IV — — — — 046045 #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 H&H .308 546346 IV — — — — 046045 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 OLYMPIC .308 546355 IV — — — — — #35 / 390575 #35 / 392635 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 REM SA ULTRA MAG .308 546347 I 046455 044160 — — 046057 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
308 NORMA MAG .308 546356 IV — — — — 046045 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 WIN SHORT MAG .308 546369 I 046453 044160 — — 046057 #35 / 390575 #35 / 392635 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 RCM .308 546353 I 046592 044111 — — 046045 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 WIN MAG .308 546352 I 046353 044112 — — 046045 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 WBY .308 546350 I 046351 044112 — — 046045 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
300 REM ULTRA MAG .308 546365 I 046447 044159 — — 046057 #5 / 390545 #5 / 392605 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
30/378 .308 546419 IV — — — — 046057 #14 / 390554 #14 / 392614 Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
307 WIN .308 — — — — — — 046045 #33 / 390573 — / — Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
309 JDJ .308 — — — — — — 046045 #27 / 390567 — / — Lg Rfl / 095316 — #9 / 390951 Large #7 / 392160
7.62x39 .308 546424 I 046425 044126 — — — #6 / 390546 #6 / 392606 Sm Rfl / 095314 — #9 / 390951 Large #7 / 392160
BLANK CART 22-45 CAL — 544591 IV — — — — — — / — — / — — / — — — / — — — / —
32/20 WIN .311 546364 III 046365 044113 — — — #7 / 390547 #7 / 392607 Sm Rfl / 095314 — #9 / 390951 Small #7 / 392160
7.65 BELG .312 546368 III 046369 044114 — — — #24 / 390564 — / — Lg Rfl / 095316 — #10 / 390952 Large #7 / 392160
303 BRITISH .312 546366 I 046367 044114 — — — #11 / 390551 #11 / 392611 Lg Rfl / 095316 — #10 / 390952 Large #7 / 392160
7.7 JAP .312 546370 III 046371 044114 — — — #1 / 390541 #1 / 392601 Lg Rfl / 095316 — #10 / 390952 Large #7 / 392160
