RECOMMENDED SPARE PARTS

The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.

6036

8990417

13-2

Wheel Hub Seal, (see Section 5), (Before S/N 0160038391 including 0160038848,
0160038853 & 0160038855)

4

Wheel Hub Seal, (see Section 5), (S/N 0160038391 & After excluding 0160038848,
0160038853 & 0160038855)

4

Wheel Hub Bearing, (see Section 5)

8

Axle Wheel Hub O-Ring, (see Section 5), (Before S/N 0160038391 including
0160038848, 0160038853 & 0160038855)

4

Axle Wheel Hub O-Ring, (see Section 5), (S/N 0160038391 & After excluding
0160038848, 0160038853 & 0160038855)

4

Strap Kit, (see Figure 5-33)

AR

Strap Kit, (see Figure 5-33)

AR

Hydraulic System

Boom Joystick Assembly, (see Figure 7-5)

1

Boom Extend/Retract Cylinder Seal Kit, (see Figure 9-1)

1

Boom Lift/Lower Cylinder Seal Kit, (see Figure 9-2), (S/N 14834 thru 19297)

1

Boom Lift/Lower Cylinder Seal Kit, (see Figure 9-2), (S/N 19298 & After)

1

Frame Sway Cylinder Seal Kit, (see Figure 9-3)

1

Attachment Tilt Cylinder Seal Kit, (see Figure 9-4)

1

Slave Cylinder Seal Kit, (see Figure 9-5), (S/N 14834 thru 19297)

1

Slave Cylinder Seal Kit, (see Figure 9-5), (S/N 19298 & After)

1

Swing Carriage Cylinder Seal Kit, (see Figure 12-3), (S/N 14834 thru 19238)

1

Swing Carriage Cylinder Seal Kit, (see Figure 12-3), (S/N 19239 & After)

1

Side Tilt Carriage Cylinder Seal Kit, (see Figure 12-4)

1

Before S/N 0160038391 including 0160038848, 0160038853 & 0160038855

Steering Cylinder Seal Kit, (see Section 5), (Before Axle S/N 829694)

1

Steering Cylinder Seal Kit, (see Section 5), (Axle S/N 829694 & After)

1

S/N 0160038391 & After excluding 0160038848, 0160038853 & 0160038855

Steering Cylinder Seal Kit, (see Section 5)

1

Hydraulic Filter Element, (see Figure 9-9), (S/N 14834 thru 19987)

1

Hydraulic Filter Element, (see Figure 9-9), (S/N 19988 & 0160002345 & After)

1

Tank Strainer, (see Figure 9-9)

1

Filler/Breather, (see Figure 9-9)

1

Fluid Level Sight Gauge, (see Figure 9-9)

1

Electrical

Engine Coolant Temperature Sender, (see Figure 10-2), (S/N 14834 thru 18231)

1

Engine Coolant Temperature Sender, (see Figure 10-2), (S/N 18231 thru 19988 &
0160002345 thru 0160004109)

1

Engine Coolant Temperature Sender, (see Figure 10-2), (S/N 0160004110 thru
0160039337 excluding 0160024571 & 0160037911)

1

Engine Oil Pressure Sender Kit, (see Figure 10-2), (Before S/N 0160012752)

1

Engine Oil Pressure Sender, (see Figure 10-2), (S/N 0160012752 thru 0160039337
excluding 0160024571 & 0160037911)

1

Fuel Level Sender Assembly, (see Figure 9-9)

1

Back-up Alarm Kit, (see Figure 10-2), (S/N 14834 thru 19988 & 0160002345 thru
0160016700)

1

Back-up Alarm, (see Figure 10-2), (S/N 0160016744 & After)

1

Part Number

Description

Qty./Machine
