CAB
6036
8990417
6-26
39
8035599
1
FOAM, .25X.5
40
8540231
1
ADAPTER, 45 DEGREES, (Before S/N 0160039337 excluding 0160024571 &
0160037911)
8540205
1
ADAPTER, 45 DEGREES, (S/N 0160039338 & After including 0160024571 &
0160037911)
41
8540218
1
ADAPTER, 90 DEGREES
42
1001100225
1
HEATER HOSE ASSY, (S/N 0160039338 & After including 0160024571 &
0160037911)
43
1001102231
1
DRAIN COCK, (S/N 0160039338 & After including 0160024571 &
0160037911)
44
2220444
1
FITTING, TEE, (S/N 0160039338 & After including 0160024571 &
0160037911)
45
1001100226
1
HEATER HOSE ASSY, (S/N 0160039338 & After including 0160024571 &
0160037911)
46
8303757
1
HEX HD CAPSCREW, 5/16-18X2-1/2, GR5, (S/N 0160039338 & After
including 0160024571 & 0160037911)
47
8307004
1
LOCKWASHER, 5/16, (S/N 0160039338 & After including 0160024571 &
0160037911)
48
8750024
1
CLAMP SET, (S/N 0160039338 & After including 0160024571 & 0160037911)
49
8750025
1
COVER PLATE, (S/N 0160039338 & After including 0160024571 &
0160037911)
50
8405202
1
CLAMP
51
8036129
4
NYLOCK NUT, #6-32
52
8033856
8
SCREW, 1/4-20X3/4
53
7139301
2
FOAM
54
70020631
1
HEATER PANEL ASSEMBLY, (includes items 5, 10, 12, 23 & 53)
K1
7148100
1
FIELD INSTALLATION HEATER KIT, (includes items 1 thru 31, 38, 39 & 50 thru
53)
Figure 6-8 Cab Heater (Continued)
Item
Part Number
Qty.
Description
Rev.
