RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
31200731 6036/6042 12-1
SECTION 12
RECOMMENDED SPARE PARTS
Part Number Description Qty./Machine
Boom Assembly
2713452 Tilt Cylinder Hose, (see Figure 8-7) 2
2716714 Boom Hose, (see Figure 8-7) 2
7079572 Wear Pad, (see Section 2) AR
7111572 High Capacity Wear Pad, (see Section 2) AR
7082311 Insert, Wear Pad, (see Section 2) AR
7082342 Shim, 0.075, (see Section 2) AR
7082362 Shim, 0.134, (see Section 2) AR
7096702 Wear Pad Spacer, 0.50, (see Section 2) AR
7096772 Wear Pad Spacer, 0.62, (see Figure 2-2) 1
7096882 Wear Pad Spacer, 0.62, (see Section 2) AR
7085442 Wear Pad Spacer, 0.88, (see Section 2) AR
Engine
7139077 Filler Breather Assembly, (see Figure 4-2) 1
1001121646 Fan, (if equipped for ULS), (see Figure 4-1) 1
1001098559 Fan, (if equipped for LS), (see Figure 4-1) 1
70024274 Fan Belt, (if equipped for ULS), (see Figure 4-2) 1
70024285 Fan Belt, (if equipped for LS), (see Figure 4-2) 1
Drive Train
1600429 Transmission Selector Control, (see Figure 7-3) 1
1319726 Transmission Filter, (see Figure 4-2) 1
1319726 Transmission Filter, (see Figure 5-31) 1
1319472 Wheel Hub Bearing, (see Section 5) 8
Hydraulic System
8224045 Boom Joystick Assembly, (see Figure 7-4) 1
8036502 Boom Extend/Retract Cylinder Seal Kit, (see Figure 9-2) 1
8036782 Boom Lift/Lower Cylinder Seal Kit, (6036), (see Figure 9-1) 1
8036132 Boom Lift/Lower Cylinder Seal Kit, (6042), (see Figure 9-1) 1
8035326 Frame Level Cylinder Seal Kit, (see Figure 9-5) 1
8035720 Attachment Tilt Cylinder Seal Kit, (see Figure 9-3) 1
8036747 Stabil-Trak Cylinder Seal Kit, (see Figure 9-6) 1
7028739 Tilt Compensating Cylinder Seal Kit, (see Figure 9-4) 1
2915023 Swing Carriage Cylinder Seal Kit, (see Figure 9-9) 1
70022041 Side Tilt Carriage Cylinder Seal Kit, (see Figure 9-7) 1
70021452 Grapple Bucket Cylinder Seal Kit, (see Figure 9-10) 1
7138740 Tank Strainer, (see Figure 9-13) 1
7139077 Filler/Breather, (see Figure 9-13) 2
7024441 Fluid Level Sight Gauge, (see Figure 9-13) 1
Electrical
1001145026 Fuel Level Sender Assembly, (see Figure 9-13) 1
8270621 Backup Alarm, (see Figure 10-1) 1
4360690 Ignition Switch, (see Figure 10-3) 1
70024276 Alternator, (if equipped for ULS), (see Figure 4-2) 1
