ELECTRICAL
31200731
6036/6042
10-3
Figure 10-1 Engine Compartment Electrical Installation
Item
Part Number
Qty.
Description
Rev.
1001129652
Ref
ELECTRICAL INSTALLATION, (6036), (if equipped for ULS), (not available to
order, see items 1 thru 56 on Figure 10-1 & items on Figure 10-2 for service)
G
1001129651
Ref
ELECTRICAL INSTALLATION, (6042), (if equipped for ULS), (not available to
order, see items 1 thru 56, 509 on Figure 10-1 & items on Figure 10-2
for service)
G
1
0641404
3
HEX HD CAPSCREW, 1/4-20X1/2, GR5
2
0641406
2
HEX HD CAPSCREW, 1/4-20X3/4, GR5
3
0761010
1
HEX HD CAPSCREW, M10X20, GR8.8, (torque to 31 lb-ft/43 Nm)
6
4240017
7
TIE STRAP
7
4711400
5
WASHER, 1/4
8
4812000
1
WASHER, 10mm
16
8270621
1
BACK-UP ALARM
18
8305624
2
HEX LOCKNUT, 1/4-20
19
8305645
1
HEX LOCKNUT, 3/8-16, (torque to 31 lb-ft/43 Nm)
23
8307110
1
WASHER, 3/8
25
8310046
1
LOCKWASHER, 10mm
30
1001127212
Ref
RELAY PANEL INSTALLATION, (includes items 101 thru 112)
D
31
1001128663
1
BATTERY CABLE, NEGATIVE
34
1001142513
Ref
BATTERY INSTALLATION, (not available to order, see items 301 thru 304
for service)
A
35
Ref
ENGINE/CHASSIS HARNESS, (see Figure 10-7 for details)
38
1001129768
1
STARTER POWER CABLE
39
1001129769
1
BUSS POWER CABLE
40
1001129795
1
GRID HEATER POWER CABLE
41
1001129796
1
ALTERNATOR POWER CABLE
42
1001129797
1
HTR FUSE TO HTR RELAY
43
1001130568
1
ALTERNATOR GROUND CABLE
44
1001130927
1
TEMPORARY MAF/WIF HARNESS
45
8750027
1
TWIN CLAMP
46
3290801
1
HEX NUT, M8X1.25
47
4831900
1
LOCKWASHER, 8mm
48
8305652
1
HEX NUT, M6X1
49
8303739
1
HEX HD CAPSCREW, 0.312-18X1.25, GR5
50
8303746
1
HEX HD CAPSCREW, 0.312-18X1.750, GR5
51
8750015
1
TWIN CLAMP SET
52
8769128
2
TWIN COVER PLATE
53
1001133172
1
ENGINE GROUND CABLE, (Before S/N 0160046471)
54
1001134452
Ref
RELAY PANEL COVER INSTALLATION, (not available to order, see items
401 thru 404 for service)
D
55
4831700
1
LOCKWASHER, 6mm
56
1001135710
1
STARTER GROUND CABLE
101
0641415
2
HEX HD CAPSCREW, 1/4-20X1-7/8, GR5
102
4761400
2
LOCKWASHER, 1/4
103
8303545
5
HEX HD CAPSCREW, M6X14, GR8.8
104
8307219
5
WASHER, 6mm
105
1001117308
1
RELAY, 20 AMP, (includes items 201 thru 204)
A
106
1001118245
1
FUSE, 25 AMP
107
1001126581
1
RELAY MOUNT BRACKET
108
1001127694
1
POWER MODULE RELAY, RED
