Fast & Fluid HA650 - Manual (Page 22)

22
Installation HA450 / HA650 V. 1.0
4.1.3 Remove the transport brackets at the rear
1. Open the back cover (A). Use the key (B).
2. Remove the back cover. Let the back cover move towards
you. Then lift the cover.
3. Unscrew the transport brackets (C) and (D) and remove
them.
4.1.4 Remove the wooden beams
1. Remove the wooden beams.
4.1.5 Remove the plastic protection on the canisters
1. Remove the blue tape and open the top cover.
2. Remove the plastic protection.
10mm
B
D
A
C
