6. Secure the cable to the handle using the
clips.(See Figure 6)
Figure 6
7.Attaching the Grass Catcher to the Mower Base
Note:This mower can be used with or without
grass catcher.
Step1:1.Place the 2 Grass Catcher side bar hooks
Reel Mower as shown in Figure 7.
onto both sides of the Grass Catcher Hooks on
both sides of the Grass Catcher Hooks on back of
Figure 7
Step 2:Wrap the Security Belt, located on the back
the grass catcher, around the center joint of the
Lower handles and lock buckle into place, as
shown in Figure G (also refer to figure on front
cover for reference if needed).Note the length
of the Security Belt can be adjusted by modifying
the Security Belt Length Adjustment Loop.
of
(Figure 8)
Figure 8
5. Once the Handle is assembled connect the plug on the handle cable to the
socket on the main unit. Tighten the screw ring to secure the cable.
(See Figure 5)
Figture 5
3 cable
6
Owner’s Manual
For external charging, first turn the knob on the battery lid counter-clockwise
on a flat, non-slip surface, and plug the charger connector onto the battery
socket, charge the battery for 24 hours each time.
To refit the battery, lower it into the cavity on the top of the product in the correct
orientation. Ensure the handle is pressed down and then turn the knob on the lid
clockwise. If the battery does not fit correctly remove it and check there are no
BATTERY CHARGING AND RECHARGING
Before First use charge the battery for 24 hours
The battery does not have to be removed from the product to be charged.
To charge the battery in the product, and plug the charger connector onto the
battery socket.
Charging the battery in
the product.
then raise the handle and lift battery out of the machine. Place the battery
Charging battery out of the machine
obstructions.
RED LED means charging
