This mower is designed for use on residential lawns. It is not designed
for commercial use or for use in public facilities, parks, sporting
grounds, roads, or in agriculture or forestry areas.
This mower is for cutting lawns only. It must not be used to trim
hedges, bushes or shrubs, for cutting or pruning, or for any mowing
where both wheels and the roller are not fully supporting the mower.
PART LIST
Please check when unpacking the unit to be sure that all items listed
below are included:
Owner’s Manual
PART LIST
1.Main Unit
2.Safety Switch
3.Level Switch
4.Battery Pack
5.Grass Catcher
6.Upper Handle
7.Middle Handle X 2
8.Lower Handle
9.Nuts and Bolts X 8
10.Charging Adaptor
11.Height Adjustment Knob
12.Cable Clips X 3
1
2
3
6
7
8
11
4
9
12
10
5
13.On/Off Switch
14.Reset Button
13 14
4
1. Set the cutting height to the highest setting.
This will make it easier attach the lower
Owner’s Manual
ASSEMBLY
to
Unpack and remove the whole unit from packaging, and ensure all the parts
are present.(See Figure 1)
2. Fit the Lower handle onto the two large lugs
Fit one
opposite lug.
handle section.
on the Main Unit. side and then flex
the other side of the handle until it fits the
(See Figure 2) Figure 2
3. Assemble the Upper Handle to the Middle Handle.
Use 2 sets of the nuts and bolts to secure in place.
Make sure that when the Upper Handle is facing up
(safety button facing up)
If you have incorrectly assembled this part,disconnect.
and re-assemble in the correct orientation.
Figture 3
4.Use 2 sets of the nuts and bolts to assemble the Upper and Middle Handle
assembly to the Lower Handle.
The nuts should be positioned on the inside of the handle and the bolts on
the outside. (See Figure 4)
Figture 4
(See Figure 3)
This side Up
