ARB 3936020 User Manual
Page 9
13/6/08
Page 9 of 11
3786946
15.
Bolt the deflector to the original bolts located in
the chassis cross member.
Tie the power steering lines to the chassis
away from sharp edges and moving parts with
cable ties provided.
16.
Using two people, three if winch fitted, position
the bar assembly on the vehicle mounts. Make
sure the deflector is held down for the bar to
be pushed back.
17.
Bolt the bar to the mounts using M12 bolts,
large flat washers and spring washers. Align
the bar to the profile of the guards and tighten
all bolts including the mount brackets.
