ARB 3436030 User Manual
Page 3
13/12/05
Page 3 of 12
3783101
BAR TO MOUNT ASSEMBLY
6151255
6
BOLT M12 X 40mm
4581050
6
WASHER SPRING M12
4581049
12
WASHER FLAT M12
4581048
4
WASHER SPRING M10
6151189
6
NUT
M12
6151321
4
NUT M10 FLANGED
6151232
4
BOLT M10 X 30mm
4581040
4
WASHER FLAT 3/8”
INDICATOR ASSY
6821151R
1
INDICATOR ASSY RHS
6821151L
1
INDICATOR ASSY LHS
6151308
4
SCREW
SELF
TAPPING
6821116
4
NUT NYLON PLUG
6821152
2
LOOM
180701
6
SCOTCH
LOCKS
180302
4
CABLE
TIE
SUPPLIMENTARY KIT 6171926 FOR WINCH RELIEF FOR 2005ON BAR ONLY
4681176
1
BRACE
3756735
1
BRACKET
ANGLE
6151143
8
SELF DRILL SCREW
NOTE: Shipping brackets connecting bull bar
to pallet and associated fasteners are not
intended to be reused in fitted bar assembly.
