ARB 3436030 User Manual
Warning
13/12/05
Page 1 of 12
3783101
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA: (08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
ARB COMBINATION WINCH/NON-WINCH BULL BARS TO SUIT FORD
F250/350 PICKUPS 2000-2004 AND 2005 MODELS ON.
PRODUCTS No. 3436030/40
FITTING KITS No.6171871, 6171873,
6171926 (SUPP. KIT FOR WINCH FITMENT 3436040
ONLY)
WARNING
FOR VEHICLES EQUIPPED WITH SRS AIRBAG
WHEN INSTALLED IN ACCORDANCE WITH THESE INSTRUCTIONS, THE FRONT
PROTECTION BAR DOES NOT AFFECT OPERATION OF THE SRS AIRBAG.
TAKE NOTE OF THE FOLLOWING:
• THIS PRODUCT MUST BE INSTALLED EXACTLY AS PER THESE INSTRUCTIONS USING
ONLY THE HARDWARE SUPPLIED.
• IN THE EVENT OF DAMAGE TO ANY BULL BAR COMPONENT, CONTACT YOUR
NEAREST AUTHORISED ARB STOCKIST. REPAIRS OR MODIFICATIONS TO THE
IMPACT ABSORPTION SYSTEM MUST NOT BE ATTEMPED.
• DO NOT USE THIS PRODUCT FOR ANY VEHICLE MAKE OR MODEL, OTHER THAN
THOSE SPECIFIED BY ARB.
• DO NOT REMOVE LABELS FROM THIS BULL BAR.
• THIS PRODUCT OR ITS FIXING MUST NOT BE MODIFIED IN ANY WAY.
Note :
1
These winch bumpers are suitable for Warn 10, 12, 15, and 16500lb
winches.
Tools Required
Metric Spanner and Socket set
Phillips head screwdriver,
Dia 12.5mm & 10mm drill bits
13mm capacity electric drill.
Plastic trimming cutting tool
Allen (Hex) Key Set
Sikaflex - black
