ARB RD90 - Manual (Page 33)

3 Installing the Air Locker
31
3.14 A B Reinstalling the Differential Assembly
c Reassemble the differential assembly according to your vehicle
manufacturer’s service manual using gasket sealant where
necessary.
NOTE : Be careful not to damage the sintered bushings in the
ends of the Air Locker when installing axle stubs. The
fit should be snug, and light tapping may be required
to fully insert the stubs fully into the splines. In some
cases a small chamfer may need to be ground onto
the axle stubs as a lead-in for insertion into the
bushings.
c Install the differential assembly into the vehicle.
c Insert both CV axles fully into the housing and gently tap them
inward until the retaining clips have seated.
NOTE : Be careful not to damage oil seals with the axles.
c Reassemble brakes and wheels according to your vehicle’s service
manual.
c Reconnect the drive shaft flange.
