7 Parts List
40
7.2
Itemized Parts List
(see exploded diagram Fig.26. )
AIR LOCKER MODEL No. :
RD110
ITEM #
QTY
DESCRIPTION
PART #
1
1
BONDED SEAL
160701
2
1
CLUTCH GEAR
050802
3
8
RETURN SPRING
150113
4
1
LONG CROSS SHAFT
061302
5
1
SPIDER BLOCK
070503
6
1
DIFFERENTIAL CASE
013107
7
3
CROSS SHAFT RETAINING PIN
120601
8
---
TAPERED ROLLER BEARING
NOT SUPPLIED
9
1
SHIM KIT
SHK002
10
1
TAPERED ROLLER BEARING
160117
11
1
SEAL HOUSING ASSEMBLY
081701
12
2
SEAL HOUSING O-RING
160233
13
1
FLANGE CAP ASSEMBLY
028507
14
1
LOCKING SIDE GEAR
131605H
15
4
PINION THRUST WASHER
151112
16
4
PINION GEAR
140801H
17
2
SHORT CROSS SHAFT
061402
18
1
SIDE GEAR
131505H
19
2
SIDE GEAR THRUST WASHER
151011
20
2
CSK SCREW
200213
21
1
ANTI-FRICTION BUSHING (PTFE)
160803
*
1
NYLON AIR LINE (5mm Dia X 6m long)
170301
*
1
BULKHEAD KIT, 3.5mm O-RING TYPE
170105
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
SOLENOID VALVE (12V)
180103
*
10
CABLE TIE
180301
*
1
NIPPLE, 1/8” BSP, MALE TO MALE
170501
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (FRONT)
180210
*
1
BUMPER STICKER
210102
*
1
WARNING STICKER
210101
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102110
*
Not illustrated in exploded view.
