8 Parts List
40
8.2
Itemized Parts List
(See exploded diagram figure 22.)
AIR LOCKER MODEL No. :
RD85
ITEM # QTY DESCRIPTION
PART #
01
1
FLANGE CAP
021503
02
1
CLUTCH GEAR
050202
03
1
DIFFERENTIAL CASE
012702
04
4
RETURN SPRING
150101
05
3
CROSS SHAFT RETAINING PIN
120303
06
1
LONG CROSS SHAFT
060205
07
2
SHORT CROSS SHAFT
060402
08
1
PISTON
040202
09
1
BONDED SEAL
160702
10
1
CYLINDER CAP
030805
11
2
SEAL HOUSING O-RING
160227
12
8
CYLINDER CAP RETAINING BOLT
200205
13
8
LOCKING TAB (8mm)
150401
14
1
TAPERED ROLLER BEARING
160115
15
1
SEAL HOUSING
080705
16
1
SHIM KIT
SHK001
17
1
SPLINED SIDE GEAR
130412
18
4
PINION THRUST WASHER
151102
19
4
PINION GEAR
140201
20
1
SPIDER BLOCK
070201
21
1
SIDE GEAR
130212
22
2
SIDE GEAR THRUST WASHER
151006
*
1
BULKHEAD FITTING KIT (O-RING TYPE)
170105
*
1
PUSH-IN FITTING (5mm to 1/8”BSPP)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE (1/8” to 1/8” BSPT)
170501
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH
180209
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
210285
* Not illustrated in exploded view.
