7 Parts List
42
7.2
Itemized Parts List
(See exploded diagram figure 26.)
AIR LOCKER MODEL No. :
RD168
ITEM # QTY
DESCRIPTION
PART #
1
1
SPLINED SIDE GEAR
728K041C**
2
1
SPIDER BLOCK
070404
3
1
LONG CROSS SHAFT
061501
4
1
SIDE GEAR
728K041C**
5
2
SIDE GEAR THRUST WASHER
151007
6
2
COUNTERSUNK SCREW
200214
7
2
CROSS SHAFT RETAINING PIN
120601
8
2
SEAL HOUSING O-RING
160248
9
1
SEAL HOUSING ASSEMBLY
082104
10
2
SHIM KIT
SHK001
11
2
TAPERED ROLLER BEARING
NOT SUPPLIED
12
1
FLANGE CAP ASSEMBLY
028605
13
1
BONDED SEAL
160703
14
1
CLUTCH GEAR
050807
15
12 RETURN SPRING
150107
16
2
SHORT CROSS SHAFT
061601
17
3
PINION GEAR
728K041C**
18
3
PINION THRUST WASHER
151113
19
1
DIFFERENTIAL CASE
013207
*
1
MASTER SHIM
150331
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170111
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (FRONT)
180210
*
1
SWITCH COVER (REAR)
180211
*
10 CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATION & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102168
* Not illustrated in exploded view.
** Available only as complete 5 gear set
