2 Removing the Existing Differential
8
2.6 Removing the Differential Carrier
Remove the adjuster nut locking tabs.
Remove the bearing caps from the third member.
Remove the adjuster nuts.
Carefully remove the differential carrier from the third member.
NOTE : The differential center is heavy and quite difficult to
handle when covered in oil. Do not drop it!
Remove the tapered roller bearings from the differential carrier with a
bearing puller. (Fig.3.)
HINT :
Check the condition of the bearing for wear and discard
if damaged.
Figure 3.
Secure the original differential to a work bench.
Remove the bolts that hold the ring gear in place.
NOTE : Chrysler 8.25” ring gear bolts are usually left hand
threaded.
Using a plastic or copper hammer, tap in a circle around the ring gear
to separate it from the differential carrier.
