—16—
DETAILED COOLING CAPACITIES* continued
See notes on page 38.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
KW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
598B024-A Outdoor Section With FV4ANF003 Indoor Section - High Speed continued
600
72 29.76 14.87 1.78 27.81 14.05 1.91 25.82 13.24 2.04 23.82 12.45 2.16 21.77 11.66 2.28 19.62 10.86 2.39
67 26.74 17.46 1.74 24.91 16.63 1.86 23.07 15.82 1.98 21.24 15.03 2.10 19.34 14.23 2.21 17.40 13.43 2.31
63†† 24.54 16.81 1.71 22.83 15.98 1.82 21.11 15.18 1.94 19.35 14.36 2.05 17.58 13.57 2.14 15.79 12.79 2.24
62 23.95 20.00 1.70 22.24 19.17 1.81 20.53 18.34 1.92 18.82 17.50 2.03 17.10 16.62 2.13 15.50 15.50 2.22
57 21.78 21.78 1.66 20.56 20.56 1.78 19.33 19.33 1.89 18.08 18.08 2.01 16.81 16.81 2.12 15.50 15.50 2.22
700
72 30.82 15.67 1.83 28.72 14.82 1.96 26.61 13.99 2.09 24.49 13.18 2.22 22.30 12.36 2.34 20.03 11.53 2.45
67 27.70 18.67 1.79 25.75 17.82 1.91 23.81 16.98 2.03 21.84 16.16 2.15 19.83 15.33 2.26 17.78 14.51 2.36
63†† 25.44 17.96 1.76 23.63 17.11 1.87 21.78 16.27 1.99 19.90 15.43 2.10 18.03 14.61 2.20 16.14 13.80 2.29
62 24.81 21.62 1.75 22.99 20.73 1.86 21.20 19.84 1.98 19.38 18.88 2.09 17.69 17.69 2.19 16.27 16.27 2.30
57 23.08 23.08 1.72 21.77 21.77 1.84 20.43 20.43 1.96 19.07 19.07 2.08 17.69 17.69 2.19 16.28 16.28 2.30
800
72 31.61 16.39 1.87 29.41 15.52 2.01 27.21 14.68 2.14 24.96 13.84 2.27 22.68 13.00 2.38 20.33 12.15 2.50
67 28.43 19.79 1.83 26.40 18.92 1.96 24.35 18.06 2.08 22.28 17.21 2.20 20.18 16.37 2.31 18.05 15.51 2.41
63†† 26.14 19.02 1.80 24.22 18.15 1.92 22.27 17.28 2.04 20.32 16.42 2.15 18.37 15.58 2.25 16.38 14.70 2.34
62 25.47 23.09 1.79 23.60 22.15 1.91 21.71 21.13 2.02 19.90 19.90 2.14 18.41 18.41 2.25 16.89 16.89 2.36
57 24.18 24.18 1.77 22.76 22.76 1.89 21.35 21.35 2.02 19.90 19.90 2.14 18.42 18.42 2.25 16.90 16.90 2.36
900
72 32.25 17.07 1.91 30.00 16.20 2.05 27.67 15.33 2.18 25.33 14.47 2.31 22.98 13.62 2.43 20.55 12.76 2.55
67 29.04 20.87 1.88 26.93 19.98 2.00 24.77 19.10 2.13 22.62 18.23 2.25 20.46 17.36 2.36 18.24 16.44 2.46
63†† 26.72 20.05 1.84 24.69 19.14 1.96 22.67 18.26 2.08 20.66 17.39 2.19 18.60 16.48 2.30 16.57 15.54 2.39
62 26.04 24.47 1.84 24.09 23.42 1.95 22.19 22.19 2.07 20.63 20.63 2.20 19.06 19.06 2.31 17.43 17.43 2.43
57 25.15 25.15 1.82 23.68 23.68 1.95 22.16 22.16 2.07 20.64 20.64 2.20 19.06 19.06 2.31 17.44 17.44 2.43
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CK5PA 024 1.00 1.02 CE3AA 024 0.99 1.04
030 1.00 1.01 030 1.00 1.03
036 1.00 1.01 036 1.00 1.03
CK5PT 036 1.00 1.01
CK3BA
024 1.00 1.02
CK5PW 024 1.00 1.01 030 1.00 1.02
030 1.00 1.01 036 1.00 1.04
036 1.00 1.00 CK5A/CK5BW 036 1.00 1.04
COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE CK5PW 036 1.00 1.04
CC5A/CD5AA 024 0.97 1.01 COILS + 355MAV042060 VARIABLE SPEED FURNACE
030 0.98 1.01 CC5A/CD5AA 024 0.98 1.04
036 1.00 1.02 030 1.00 1.03
CC5A/CD5AW 024 0.98 1.01 036 1.00 1.03
030 0.98 1.01 CC5A/CD5AW 024 0.98 1.03
036 1.00 1.02 030 1.00 1.03
CE3AA 024 0.98 1.02 036 1.00 1.03
030 0.99 1.01 CE3AA 024 0.99 1.04
036 1.00 1.02 030 1.00 1.03
CK3BA 024 0.99 1.01 036 1.00 1.03
030 1.00 1.01 CK3BA 024 1.00 1.03
036 1.00 1.02 030 1.00 1.03
CK5A/CK5BA 024 1.00 1.04 036 1.00 1.04
030 1.00 1.03 CK5A/CK5BA 024 1.00 1.05
036 1.00 1.02 030 1.00 1.05
CK5A/CK5BT 036 1.00 1.02 036 1.00 1.04
CK5A/CK5BW 024 1.00 1.03 CK5A/CK5BT 036 1.00 1.04
030 1.00 1.03 CK5A/CK5BW 024 1.00 1.05
CK5PA 024 1.00 1.04 030 1.00 1.05
030 1.00 1.03 036 1.00 1.04
036 1.00 1.02 CK5PA 024 1.00 1.05
CK5PT 036 1.00 1.02 030 1.00 1.05
CK5PW 024 1.00 1.03 036 1.00 1.04
030 1.00 1.03 CK5PT 036 1.00 1.04
COILS + 355MAV042040 VARIABLE SPEED FURNACE CK5PW 024 1.00 1.05
CC5A/CD5AW 036 1.00 1.04 030 1.00 1.05
— — — 036 1.00 1.04
