Rat Tail & Angle
Grinders
Specifications
Rating 120V
Amperage 12
Max. Motor HP 2.0
No Load RPM 11,000
Wheel Diameter 5"
Wire Cup Brush 3"
Spindle Thread 5/8"-11"
Wire Wheel 4"
Length (in.) 14-3/4"
Weight (lbs.) 5.3
Includes
Guard ...................................... 0 605 510 378
Vibration Dampening Side
Handle ................................. 1 602 025 052
5" Grinding wheel (2) ............ 2 610 917 845
Flange Kit ............................... 2 610 906 323
Spanner Wrench .................... 1 607 950 043
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• Powerful & Durable - For the most demanding
jobs / compact and light weight for all day use
• 2-Position Vibration Control™ Handle - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• Kickback Stop™ - Shuts tool off should the wheel
get into a bind situation
• Comfort Grip Rear Handle Trigger
• Epoxy Coated Field Windings - Provides the ultimate
protection against abrasive dust and metal debris
• Restart Protection - Shuts the tool off should the
power supply be interrupted
• Constant Response™ Circuitry - Provides soft-start,
constant speed under load and overload protection
• Sealed Switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Tool-Free Adjustable Guard - Quick guard
installation and adjustments
1824ED also features
• No lock-on switch to conform with
OSHA regulations
1824E 5" Mid Size Rat Tail Grinder
1824ED 5" Mid Size Rat Tail Grinder (not shown)
Specifications
Rating 120V
Amperage 12.0
Max. Motor HP 2
No Load RPM 9,300
Wheel Diameter 6"
Wire Cup Brush 3"
Spindle Thread 5/8"-11"
Wire Wheel 4"
Length (in.) 11-3/4"
Weight (lbs.) 5.0
Includes
Guard ...................................... 1 605 510 379
Vibration Dampening Side
Handle ................................. 1 602 025 052
Flange Kit (inner and outer wheel flanges)
.............................................. 2 610 906 323
Spanner Wrench .................... 1 607 950 043
Abrasive Wheel ...................... 2 610 917 846
Large Backing Flange ............ 1 605 703 127
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• 2-Position Vibration Control™ Handle - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• Constant Response™ Circuitry - Provides
soft-start, maintains constant speed under
load, provides overload protection
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Epoxy Coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• 5/8" - 11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle Lock - For quick wheel changes
• Tool-free adjustable guard - Quick guard
installation and adjustments
• Kickback Stop™ - Shuts the tool down should the
wheel get into a bind situation
• Restart Protection - Shuts the tool down should
the power supply be interrupted
• Directed Air Flow - Unique design diverts dust
away from switch and vital components
1806E
6" Angle Grinder
See pages 167–170, 173,
175–177, 179–182 for
grinder accessories.
BOSCH
See pages 167–171, 173,
175–177, 179–182 for
grinder accessories.
BOSCH
Specifications
1853-5 1853-6
Rating 120V AC/DC 120V AC/DC
Amperage 15 15
Max. Motor HP 3 3
No Load RPM 5,000 6,000
Wheel Diameter 7" or 9" 7" or 9"
Spindle Thread 5/8"-11 5/8"-11
Wire Wheel up to 6" up to 5"
Flared Cup
Wheels
up to 6" up to 5"
Length (in.) 17.5" 17.5"
Weight (lbs.) 10.5 10.5
Includes
Vibration Control™ Auxiliary
Handle ................................. 1 602 025 030
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• 15 Amps, 5,000 RPM
• Vibration Control™ Side and Main Handles
- Reduces vibration up to 60%, providing
uncompromising user comfort for extended
periods of work
• Metal Gear Cover - Maximum durability
• AC/DC Capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Epoxy-coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• Precision spiral bevel gears - Quality engineering
and construction for smooth power transmission
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
1853-5 7"/9" Large Angle Sander
1853-6 7"/9" Large Angle Sander (not shown)
See pages 167–171,
173–177, 179–182 for
grinder accessories.
