Bosch 1810PS - Manual (Page 7)

157 Toll Free: 877-BOSCH-99 Boschtools.com
Paddle Switch & Angle
Grinders
Specifications
1810PS 1810PSD
Rating 120V AC/DC 120V AC
Amperage 8.0 8.0
Max. Motor HP 1.1 1.1
No Load RPM 11,000 11,000
Wheel Diameter 4 1/2" 4 1/2"
Wire Cup Brush 3" —
Spindle Thread 5/8"-11" 5/8"-11"
Wire Wheel 4" —
Length (in.) 11-1/4" 11-1/4"
Weight (lbs.) 4.3 4.3
Includes
Guard ...................................... 1 605 510 377
Vibration Dampening Side
Handle ................................. 1 602 025 052
Flange Kit (inner and outer wheel flanges)
.............................................. 2 610 906 323
Spanner Wrench .................... 1 607 950 043
1810PS
Abrasive Wheel ...................... 2 610 917 844
1810PSD
Abrasive Wheel ...................... 2 608 600 506
1810PS 4-1/2" Paddle Switch Grinder
1810PSD 4-1/2" Paddle Switch Grinder (not shown)
See pages 167–170, 173,
175–177, 179–182 for
grinder accessories.
BOSCH
Specifications
1811PS 1811PSD
Rating 120V AC/DC 120V AC/DC
Amperage 9.0 9.0
Max. Motor HP 1.8 1.8
No Load RPM 11,000 11,000
Wheel Diameter 5" 5"
Wire Cup Brush 3" 3"
Spindle Thread 5/8"-11" 5/8"-11"
Wire Wheel 4" 4"
Length (in.) 11-3/4" 11-3/4"
Weight (lbs.) 4.8 4.8
Includes
Guard ...................................... 1 605 510 378
Vibration Dampening Side
Handle ................................. 1 602 025 052
Flange Kit (inner and outer wheel flanges)
.............................................. 2 610 906 323
Spanner Wrench .................... 1 607 950 043
Abrasive Wheel ...................... 2 610 917 845
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• 2-Position Vibration Control™ Handle - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• AC/DC Capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Epoxy Coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• Directed Air Flow - Unique design diverts dust
away from switch and vital components
• 5/8" -11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle Lock - For quick wheel changes
• Tool-free adjustable guard - Quick guard
installation and adjustments
1811PS 5" Paddle Switch Grinder
1811PSD 5" Paddle Switch Grinder (not shown)
See pages 167–170, 173,
175–177, 179–182 for
grinder accessories.
BOSCH
Specifications
Rating 120V AC/DC
Amperage 9.5
Max. Motor HP 1.8
No Load RPM 11,000
Wheel Diameter 5"
Wire Cup Brush 3"
Spindle Thread 5/8"-11"
Wire Wheel 4"
Length (in.) 11-3/4"
Weight (lbs.) 4.8
Includes
Guard ...................................... 1 605 510 378
Vibration Dampening Side
Handle ................................. 1 602 025 052
Flange Kit (inner and outer wheel flanges)
.............................................. 2 610 906 323
Spanner Wrench .................... 1 607 950 043
Abrasive Wheel ...................... 2 610 917 845
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• 2-Position Vibration Control™ Handle - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• AC/DC capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Epoxy Coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• 5/8" -11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle Lock - For quick wheel changes
• Tool-free adjustable guard - Quick guard
installation and adjustments
• Directed Air Flow - Unique design diverts dust away
from switch and vital components
1801
5" Angle Grinder
See pages 167–170, 173,
175–177, 179–182 for
grinder accessories.
BOSCH
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• 2-Position Vibration Control™ Handle - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• AC/DC capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Sealed switch - Keeps debris out of the switch
mechanism and extends switch life
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Epoxy Coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• 5/8" -11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle lock - For quick wheel changes
• Tool-free adjustable guard - Quick guard
installation and adjustments
• Directed Air Flow - Unique design diverts dust
away from switch and vital components
1810PSD also features
• No lock-on switch to conform with OSHA regulations
1811PSD also features
• No lock-on switch to conform with OSHA regulations
