160 Boschtools.com Toll Free: 877-BOSCH-99
Angle
Grinders
Specifications
Rating 120V AC/DC
Amperage 15
Max. Motor HP 3
No Load RPM 8,500
Wheel Diameter 7"
Spindle Thread 5/8"-11
Wire Wheel up to 5"
Flared Cup Wheels up to 5"
Length (in.) 17.5"
Weight (lbs.) 11.5
Includes
Vibration Control™ Auxiliary
Handle ................................. 1 602 025 030
Wheel Guard .......................... 1 605 510 353
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• Vibration Control™ Side and Main Handles - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• AC/DC capability - Extends tool versatility by working
from DC outlets such as welders and generators
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• 5/8" - 11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle lock - For quick wheel changes
• 3-Position auxiliary handle - Specifically designed
for multiple hand positions, provides maximum
versatility and control
• Reinforced armature windings - Protects the motor
against abrasive dust and metal debris
• Ergonomic design - Slim handle for a comfortable
fit, with on-handle switch for easy operation
• Epoxy-coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• Precision spiral bevel gears - Quality engineering
and construction for smooth power transmission
1873-8 7" Large Angle Grinder with
Rat Tail Handle
1873-8D 7" Large Angle Grinder with
Rat Tail Handle (not shown)
See pages 167–171,
173–177, 179–182 for
grinder accessories.
BOSCH
Specifications
1873-6 1893-6
Rating 120V AC/DC 120V AC/DC
Amperage 15 15
Max. Motor HP 3 3
No Load RPM 6,000 6,000
Wheel Diameter 7" 9"
Spindle Thread 5/8"-11 5/8"-11
Wire Wheel up to 5" up to 5"
Flared Cup
Wheels
up to 5" up to 5"
Length (in.) 17.5" 17.5"
Weight (lbs.) 11.5 11.9
Includes
Vibration Control™ Auxiliary
Handle ................................. 1 602 025 030
7" Wheel Guard ...................... 1 605 510 353
9" Wheel Guard ...................... 1 605 510 354
(1893-6 Only)
Backing Flange and
Lock Nut Kit ........................ 2 610 906 326
Hex Key Wrench ..................... 1 607 950 038
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• Vibration Control™ Side and Main Handles - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• AC/DC capability - Extends tool versatility by working
from DC outlets such as welders and generators
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• 5/8" - 11 Spindle - Wide flexibility for mounting
most popular accessories
• Spindle lock - For quick wheel changes
• 3-Position auxiliary handle - Specifically designed
for multiple hand positions, provides maximum
versatility and control
• Reinforced armature windings - Protects the motor
against abrasive dust and metal debris
• Ergonomic design - Slim handle for a comfortable
fit, with on-handle switch for easy operation
• Epoxy-coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• Precision spiral bevel gears - Quality engineering
and construction for smooth power transmission
1873-6
7" Large Angle Grinder with
Rat Tail Handle
1893-6D 9" Large Angle Grinder with
Rat Tail Handle (not shown)
See pages 167–171,
173–177, 179–182 for
grinder accessories.
BOSCH
Specifications
Rating 120V AC/DC
Amperage 15
Max. Motor HP 4.5
No Load RPM 6,000
Wheel Diameter 9"
Spindle Thread 5/8"-11
Wire Wheel up to 5"
Flared Cup Wheels up to 5"
Length (in.) 19"
Weight (lbs.) 13.3
Includes
Vibration Control™ Auxiliary
Handle ................................. 1 602 025 030
Wheel Guard .......................... 1 605 510 354
Features
• Lock-off Switch - Avoids accidental start up
• Lock-on Switch - For extended use applications
• Vibration Control™ Side and Main Handles - Reduces
vibration up to 60%, providing uncompromising
user comfort for extended periods of work
• Rear handle rotates to optimize user comfort
in all applications
• Tool-free Adjustment Guard - Quick guard
installation and adjustments
• Metal Gear Cover - Maximum durability
• AC/DC capability - Extends tool versatility by working
from DC outlets such as welders and generators
• Service Minder™ Brushes - Eliminates guesswork,
stops tool when preventive maintenance is required
• Epoxy-coated Field Windings - Provides ultimate
protection against abrasive dust and metal debris
• Precision spiral bevel gears - Quality engineering
and construction for smooth power transmission
See pages 167–171,
173–177, 179–182 for
grinder accessories.
BOSCH
1873-8D also features
• No lock-on switch to conform with OSHA regulations
1893-6D also features
• No lock-on switch to conform with OSHA regulations
1894-6D also features
• No lock-on switch to conform with OSHA regulations
1894-6 9" Large Angle Grinder with
D-Handle
1894-6D 9" Large Angle Grinder with
D-Handle (not shown)
