Page 46
Maintenance and Lubrication Schedule
1500
Cycles
Inspect platform cable-activated manual release
system (T-handle/cable assembly and carriage move-
ment)
Inspect limit switches for securement and proper
adjustment
Inspect carriage, lifting arm and eccentric shaft rollers
(bearings) for wear or damage, positive securement
and proper operation
Inspect external snap rings (e-clips):
• Carriage roller bearings (4)
• Lower lifting arm pins (5)
• Upper lifting arm pins (2)
• Outer race bearings (2)
• Inner roll stop shaft (2)
Inspect lower lifting arm pins for wear or damage,
positive securement and proper adjustment
Inspect eccentric shaft pins, bearing mounting screw,
washers and securement hardware for wear or dam-
age, positive securement and proper operation
Ensure T-handle release and cable assembly
operate properly (see Manual Operation).
Ensure carriage can be manually extended and
retracted freely.
Resecure, replace or adjust as needed. See
Switch Adjustment.
Correct, replace damaged parts and/or
relubricate.
Resecure, replace or correct as needed.
Resecure, replace damaged parts, lubricate or
correct as needed.
Resecure, replace damaged parts, lubricate or
correct as needed. See Carriage Ride Height
Adjustment.
