1 parts list – Briggs & Stratton T22B & T22H User Manual
Page 19
17
REF #
QTY.
PART NO.
DESCRIPTION
37
1
P7958
Locking Pin
38
3
HW172809
M10 x 1.5 Lock Nut
39
2
LS400323
12" Safety Chain w/"S" Hooks
2
LS400345
"S" Hook
40
1
HW172717
M10 x 1.5 x 115mm Bolt
41
1
HW172716
M10 x 1.5 x 100mm Bolt
42
8
HW172908
10mm Washer
43
1
LS400346
Hitch Coupler for 2" Ball
44
1
HC390369
1
/
2
" Steel Tube
45
1
HC390368
1
/
2
" NPT Female x
1
/
2
" NPT Male 45º Elbow
46
1
HC390343
1
/
2
" x
1
/
2
" Nipple
47
1
HC390347
Steel Tube Fitting
48
1
HC390324
3
/
4
" NPT x
3
/
4
" Tube 45º
49
1
HC390311
3
/
4
" to
1
/
2
" Reducer
50
1
HC390302
Swivel Elbow 90º
51
1
Obtain Locally
1
/
2
" NX x 3
1
/
2
" Grade 5 Hex Cap Screw
52
1
HC390329
1
/
2
" I.D. x 42" Hydraulic Pressure Hose
53
1
HC390256
3
/
4
" I.D. x 35" Hydraulic Return Hose
54
2
LS400312B
Pre-greased Wheel Assembly
55
2
BE22176
Grease Seal
56
4
BE22175
Bearing Cone
57
4
BE22174
Bearing Cup
58
2
LS400312
4.80 x 8" Road Speed Tire
59
2
Obtain Locally
3
/
4
" Light Flat Washer
60
2
HN17120
3
/
4
" NF Slotted Nut
61
2
Obtain Locally
1
/
8
" x 1
1
/
2
" Cotter Pin
62
2
LS400332
Hub Cap
63
2
Obtain Locally
3
/
8
" NC x 1
1
/
2
" Bolt
64
6
Obtain Locally
3
/
8
" Lockwasher
65
1
LS401353
Cylinder Support Plate
66
1
LS401349
Cylinder Support
67
1
LS401354
Stripper Plate
68
4
Obtain Locally
3
/
8
" NC x 1" Grade 5 Hex Cap Screw
69
2
Obtain Locally
5
/
16
" x
3
/
4
" Hex Cap Screw
70
2
Obtain Locally
5
/
16
" Lockwasher
71
1
LS401352
Stripper Assembly
1
LS401155
Hardware Kit
7.1 PARTS LIST
R
EPLACEMENT
F
ILTER
C
ARTRIDGE
HC390601 I
NTERCHANGES
WITH
:
R
EPAIR
K
ITS
:
D
ESCRIPTION
:
FRAM 1653A
HC390423A
O-Ring Kit for Valves HC390406A & HC390406S
NAPA 1553
HC390720B
O-Ring Kit for Pumps HC390705B & HC390709
Cross #1A9023
HC390120F
O-Ring Kit for 4" x 24" Cylinder
Baldwin #BT839
HC390171
O-Ring Kit for 4 1/2" x 24" Cylinder
Wicks #51553
