Application
®
Fast Ethernet Turbo Ring
Moving process
EDS508
(page 31)
EDS508
(page 31)
AWK-1100
AWK-1100
EDS508
(page 31)
Field engineers
P O E
AWK-1200-AP
AWK-1200-AC
AWK-1100-US
Model
Function
Input Power
Temperature
Enclosure
Antenna
Other Features
Price
AWK-1100-US
AP Bridge/Client Dual 12-45VDC or PoE
0 to 60°C
DIN Mount / IP30
(2) 2 dBi external (RPSMA)
Class 1 Div 2
$648.95
AWK-1200-AP-US
AP Bridge
PoE
-20 to 70°C
Outdoor / IP67
(2) 5 dBi external (N-type)
WPA2
NEW!
1248.95
AWK-1200-AC-US
AP Client
PoE
-20 to 70°C
Outdoor / IP68
(1) 9 dBi internal
NEW!
748.95
Industrial Ethernet Wireless AP Bridge/AP Client
Access all your resources wirelessly with access points
Advanced Security Capability
• 64/128-bit WEP (Wired Equivalent Privacy)
• Enable/disable SSID Broadcasts
• MAC-address based access control
• IEE802.1x / RADIUS
• WPA (Wi-Fi Protected Access)
Useful Utilities and Remote Configuration
• Firmware upgrade from TFTP or HTTP
• Configuration backup and reset
• Web-based Management
• Supports SNMP and UPnP
Tired of the hassle of finding a place to plug into your Ethernet
system? Are you ready for the convenience of sending your
Ethernet packets over the air instead of through a wire? Now
you can access your network resources without having to plug
in or dock into your LAN. B&B Electronics has carefully selected
the AWK-1100 and AWK-1200-AP/AC to enable industrial users
to access their network resources wirelessly.
The AWK-1100-US can be configured as an Access Point
Bridge or Client. A rugged, IP30, DIN rail mountable case and
dual power inputs make this product a perfect fit for industrial
applications. Class 1 Div 2 is also a favorite feature for the oil
and gas industry. Each unit includes two 2dBi antennas.
The AWK-1200 series is sold either as a Bridge or as a Client.
These products have superior weather resistance with the IP67
and IP68 case ratings and are mountable to a mast or panel
mountable (both mounting options are included with each
radio). A PoE connection is required to power these Access
Points. The Access Point Bridge AWK-1200-AP-US includes two
5dBi antennas while the Access Point Client AWK-1200-AC-US
includes one internal 9dBi antenna.
Bridge vs Client Modes
Bridge Mode allows one-to-many while Client Mode allows
one-to-one. Networks are typically set up with an Access Point
Bridge at the main, hard-wired Ethernet connection and the
peripheral Access Points will be set up as Clients. In this
particular case, the Clients are set up in Infrastructure Mode.
Another way to use Clients is in Ad-hoc Mode, which allows
two Clients to communicate one-to-one.
Features
Benefits
Industrial IP30 or IP67/68 Enclosures. . . . . . . . . Ensures reliability in harsh industrial or
outdoor applications
Power-over-Ethernet Compatible. . . . . . . . . . . . A power supply is not required if your network
features PoE
Web Based Management. . . . . . . . . . . . . . . . . . Easy to remotely configure
64/128-bit WEP and WPA . . . . . . . . . . . . . . . . . Ensures your data remains secure
Model No.
Description
Price
EDS-WK
Panel Mount Kit for AWK-1100-US
$11.95
MDR-40-24
24VDC, 1.7A DIN Rail Power Supply, Slimline
59.00
Accessories & Power Supply
1.815.433.5100
www.bb-elec.com
