Lighting Arrestors &
MOCAP Silicone Installation Tape
Protect your antenna from weather
Antenna options
When installed properly in the feedline, a lightning arrestor
can prevent antenna damage due to lightning strikes. These
units are designed with a rugged housing and high quality
plated brass “N” connectors.
Features – Lighting Arrestors
• Impedance: 50 Ohms (nom.)
• Connector 1: N female
• Connector 2: N female (bulkhead)
Mounting
Model No.
Frequency
Gain
Style
Connector
Dimensions
Bracket
Price
FG24008
2.4 GHz
8 dB
Omni (fiber glass)
N female
24 in (60.9 cm) long
FM2
$194.95
YE240015
2.4 GHz
12.5 dB
Yagi
N female
18 in (45.7 cm) long
Included
244.95
FG9023
900 MHz
3 dB
Omni (fiber glass)
N female
25 in (63.4 cm) long
FM2
139.95
FG9026
900 MHz
6 dB
Omni (fiber glass)
N female
65 in (165.1 cm) long
FM2
179.95
YS8963
900 MHz
6 dB
Yagi
N female
16.8 in (42.7 cm) long
Included
69.95
YS8966
900MHz
9dB
Yagi
N female
27.8 in (70.6 cm) long
Included
89.95
YS89612
900MHz
11dB
Yagi
N female
49 in (124.5 cm) long
Included
154.95
FM2
Brackets for Omni-directional antennas, package of two (used for one antenna)
29.95
For long range point-to-point applications, use Yagi antennas. Multi-point applications may require a mixture of Yagi and Omni-directional antennas.
FG24008
FG9023
Shown with optional FM2 brackets
LABH350NN LABH2400NN
Cables to connect optional antennas
Max.
Breakdown
Insertion
Model No.
Power
Voltage
Loss
VSWR
Protection
Configuration
Price
LABH350NN
1000 W
350 VAC
27 to 500 MHz < 0.1 dB
0 to 150 MHz < 1.1 to 1
5000 A
Bulkhead, Pass-through
$78.95
0 to 1 GHz
1000 MHz < 0.25 dB
150 to 1000 MHz < 1.2 to 1
LABH2400NN 70 W
90 to 130
0 to 1 GHz < 0.03 dB
0 to 1 GHz < 1.1 to 1
1 shock = 20 kA
Bulkhead, Pass-through
78.95
0 to 4 GHz
VAC
1 to 4 GHz < 0.29 dB
1 to 4 GHz < 1.2 to 1
10 shocks = 10 kA
LAIL350NN
1000 W
350 VAC
27 to 500 MHz < 0.1 dB
0 to 150 MHz < 1.1 to 1
5000 A
In-line applications
NEW!
78.95
0 to 1 GHz
1000 MHz < 0.25 dB
150 to 1000 MHz < 1.2 to 1
Features & Benefits – Silicone Installation Tape
• Save installation time and labor
• Protect valuable equipment
• Material will not crack or melt in temperatures from -51 to 260° C
• Dielectric strength of 400 Volts per mil
• Tensile strength of 600 psi
• Insulates to 8000 Volts
Model No.
Description
Price
IASFST10
MOCAP tape - (6) ten inch strips, 1 inch wide
$5.95
IASFST
MOCAP tape - 36 foot roll, 1 inch wide
29.95
IASFST
IASFST10
Easy-to-use self-fusing installation tape bonds to itself in
seconds forming a permanent air and water tight seal within 24
hours. Adhesive-free formula leaves no sticky residue after
removal. Stretches up to 300% allowing it to conform to any
shape. Safe replacement for heat shrinkable sleeving. Ideal for
termination splicing, wire connections, bundling wires and
cables, masking applications and quick emergency repairs.
Model No.
Connector 1
Connector 2
Length
Material
Price
195M-SLSW-24
SMA Reverse polarity plug
RPSMA Jack bulkhead
2 ft
LMR195
$29.95
400M-NMSL-24
SMA Reverse polarity plug
N Male
2 ft
LMR400
29.95
400M-NISL-24
SMA Reverse polarity plug
N Bulkhead (female)
2 ft
LMR400
32.95
400M-NMSL-120
SMA Reverse polarity plug
N Male
10 ft
LMR400
49.95
400M-NMSL-240
SMA Reverse polarity plug
N Male
20 ft
LMR400
59.95
400M-NMSL-600
SMA Reverse polarity plug
N Male
50 ft
LMR400
119.95
400M-NMTL-24
TNC Reverse polarity plug
N Male
2 ft
LMR400
29.95
400M-NITL-24
TNC Reverse polarity plug
N Bulkhead (female)
2 ft
LMR400
32.95
400M-NMTL-120
TNC Reverse polarity plug
N Male
10 ft
LMR400
49.95
400M-NMTL-600
TNC Reverse polarity plug
N Male
50 ft
LMR400
119.95
400M-NMNM-120
N Male
N Male
10 ft
LMR400
39.95
400M-NMNM-240
N Male
N Male
20 ft
LMR400
59.95
400M-NMNM-480
N Male
N Male
40 ft
LMR400
99.95
400M-NFNM-120
N Female
N Male
10 ft
LMR400
39.95
400M-NFNM-480
N Female
N Male
40 ft
LMR400
99.95
YE240015
YS8963
Wireless Accessories
Antenna and cabling options
for longer range & special
applications
