Connect a DVD Player or other accessory digital source devices
53
English
User Man
ual
L
Pr
H
R
Pb
V
DIGITAL
AUDIO
IN
Y
Pr
Pb
Y
S-VIDEO
S-VIDEO
AV2
AV3
AV1
VIDEO
L
R
VIDEO
AV1
AV2
DVD / Cable box
AV1/AV2 :
S-VIDEO
1
2
AV1/AV2 :
L + R
Devices with an S-Video connector
1. Connect an S-Video cable to the
AV1
or
AV2 S-VIDEO
input 1.
2. Connect the audio cables to the device’s
AUDIO L
and
R
jacks and to the
L
and
R
audio
AV1
or
AV2
jacks 2 on the TV
accordingly to where you connected the S-
Video cable.
3. Select the equipment you have connected in
the Installation menu, Connections, p. 36
and and link it to the
AV
connector you
have connected to.
Tip:When using the
S-VIDEO
connector
do not connect any device to the
AV
VIDEO
input that you are using.
2572.3 en 22-03-2007 13:16 Pagina 53
