DETAILED COOLING CAPACITIES* Continued
See notes on page 18.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
594D048-E, F Outdoor Section With CC5A/CD5AA060 Indoor Section
1500
72 52.3 25.6 4.37 50.2 24.8 4.90 47.9 24.0 5.48 45.6 23.1 6.11 43.1 22.2 6.78
67 48.3 32.5 4.35 46.3 31.7 4.87 44.2 30.8 5.45 42.1 29.9 6.08 39.8 29.0 6.73
62 44.4 39.2 4.34 42.5 38.3 4.86 40.6 37.3 5.43 38.5 36.2 6.05 36.5 35.1 6.70
57 42.0 42.0 4.29 40.5 40.5 4.81 39.0 39.0 5.38 37.4 37.4 5.99 35.7 35.7 6.64
1700
72 53.1 26.6 4.45 50.8 25.8 4.97 48.5 24.9 5.55 46.1 24.1 6.19 43.5 23.1 6.86
67 49.1 34.2 4.42 47.0 33.4 4.95 44.8 32.5 5.52 42.5 31.6 6.15 40.2 30.6 6.81
62 45.1 41.5 4.41 43.2 40.5 4.93 41.2 39.4 5.50 39.1 38.2 6.12 37.1 36.8 6.78
57 43.4 43.4 4.37 41.8 41.8 4.89 40.2 40.2 5.46 38.5 38.5 6.08 36.8 36.8 6.73
1800
72 53.4 27.0 4.49 51.1 26.2 5.01 48.7 25.4 5.59 46.3 24.5 6.22 43.7 23.6 6.90
67 49.3 35.0 4.46 47.3 34.2 4.98 45.1 33.3 5.56 42.8 32.4 6.19 40.4 31.4 6.85
62 45.4 42.5 4.44 43.5 41.5 4.97 41.5 40.3 5.54 39.4 39.0 6.16 37.4 37.4 6.82
57 44.0 44.0 4.41 42.4 42.4 4.93 40.8 40.8 5.50 39.1 39.1 6.12 37.3 37.3 6.78
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 1.00 1.00 CK5A/CK5BX 060 1.00 0.94
CC5A/CD5AC 048 0.96 0.99 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CC5A/CD5AW 048 0.98 1.00 CC5A/CD5AA 060 0.99 0.95
060 1.03 1.00 CC5A/CD5AW 048 0.98 0.95
CD5AA 048 0.99 1.00 060 1.00 0.95
CE3AA 048 0.99 1.00 CK3BA 060 0.99 0.95
060 1.03 1.00 CK5A/CK5BA 060 0.99 0.95
CF5AA 048 0.99 0.99 CK5A/CK5BW 048 0.98 0.95
CK3BA 048 0.99 1.00 CK5A/CK5BX 060 1.00 0.95
060 1.00 1.00 COILS + 355MAV042080 VARIABLE SPEED FURNACE
CK5A/CK5BA 048 0.99 1.00 CD5AA 048 0.98 0.97
060 1.00 1.00 CK3BA 048 0.98 0.97
CK5A/CK5BN 048 0.96 0.98 CK5A/CK5BA 048 0.98 0.97
060 1.00 1.00 COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK5A/CK5BT 048 0.99 1.00 CC5A/CD5AA 060 0.98 0.98
060 1.00 1.00 CC5A/CD5AW 060 1.00 0.98
CK5A/CK5BW 048 0.99 1.00 CD5AA 048 0.98 0.98
CK5A/CK5BX 060 1.03 1.00 CK3BA 048 0.98 0.98
F(A,B)4AN(F,B,C) 048 0.99 1.02 CK5A/CK5BA 060 0.99 0.98
060 1.03 1.03 CK5A/CK5BX 060 1.00 0.98
FB4ANB 070 1.03 1.02 CK5ACK5BA 048 0.98 0.98
FC4BN(F,B) 048 1.00 1.02 COILS + 355MAV060100 VARIABLE SPEED FURNACE
060 1.03 1.03 CC5A/CD5AA 060 0.98 0.96
FC4BNB 070 1.03 1.02 CC5A/CD5AC 048 0.96 0.97
FG3AAA 048 0.98 1.00 CC5A/CD5AW 060 1.00 0.96
060 1.01 1.00 CD5AA 048 0.98 0.96
FK4CNB 006 1.04 0.94 CK3BA 048 0.98 0.96
FK4CNF 005 1.03 0.95 060 0.99 0.96
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CK5A/CK5BA 048 0.98 0.96
CC5A/CD5AC 048 0.96 0.97 CK5A/CK5BA 060 0.98 0.96
CD5AA 048 0.98 0.97 CK5A/CK5BX 060 1.00 0.96
CK3BA 048 0.98 0.97 COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK5A/CK5BA 048 0.98 0.97 CC5A/CD5AA 060 0.98 0.96
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE CC5A/CD5AW 048 0.98 0.96
CC5A/CD5AA 060 1.00 0.94 060 1.00 0.96
CC5A/CD5AW 048 0.98 0.94 CK3BA 060 0.99 0.96
060 1.00 0.94 CK5A/CK5BA 060 0.98 0.96
CK3BA 060 1.00 0.94 CK5A/CK5BW 048 0.98 0.96
CK5A/CK5BA 060 1.00 0.94 CK5A/CK5BX 060 1.00 0.96
CK5A/CK5BW 048 0.98 0.94 — — —
