—11—
COMBINATION RATINGS Continued
* Tested Combination
† In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Bryant furnaces are equipped with TDR except for the 394HAD.
‡ Based on computer simulation. TXV must be hard shutoff type.
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other
combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Minimum outdoor operating ambient in cooling mode is 55°F (12.8°C), maximum 125°F (51.7°C).
UNIT
SIZE-SERIES
INDOOR
MODEL
TOT. CAP.
BTUH
FACTORY
SUPPLIED
ENHANCE-
MENT
SEER
EERA
STANDARD
RATING
BRYANT GAS
FURNACE OR
ACCESSORY
TDR†
ACCESSORY
TXV‡
048-E/F
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,500 TDR 11.50 — 11.50 10.15
CC5A/CD5AW048 46,000 TDR 11.20 — 11.20 10.05
CC5A/CD5AW060 47,000 TDR 12.00 — 12.00 10.45
CK3BA060 46,500 TDR 11.50 — 11.50 10.35
CK5A/CK5BA060 46,500 TDR 11.50 — 11.50 10.35
CK5A/CK5BW048 46,000 TDR 11.20 — 11.20 10.10
CK5A/CK5BX060 47,000 TDR 12.00 — 12.00 10.60
COILS + 355MAV042080 VARIABLE SPEED FURNACE
CD5AA048 46,000 TDR 11.00 — 11.00 9.70
CK3BA048 46,000 TDR 11.00 — 11.00 9.75
CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.75
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,000 TDR 11.00 — 11.00 9.70
CC5A/CD5AW060 47,000 TDR 11.20 — 11.20 9.95
CD5AA048 46,000 TDR 11.00 — 11.00 9.60
CK3BA048 46,000 TDR 11.00 — 11.00 9.70
CK5A/CK5BA060 46,500 TDR 11.00 — 11.00 9.90
CK5A/CK5BX060 47,000 TDR 11.20 — 11.20 10.15
CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.70
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,000 TDR 11.20 — 11.20 9.95
CC5A/CD5AC048 45,000 TDR 11.00 — 11.00 9.70
CC5A/CD5AW060 47,000 TDR 11.80 — 11.80 10.20
CD5AA048 46,000 TDR 11.00 — 11.00 9.90
CK3BA048 46,000 TDR 11.00 — 11.00 9.95
CK3BA060 46,500 TDR 11.20 — 11.20 10.15
CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.95
CK5A/CK5BA060 46,000 TDR 11.20 — 11.20 10.40
CK5A/CK5BX060 47,000 TDR 11.80 — 11.80 10.40
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,000 TDR 11.20 — 11.20 9.95
CC5A/CD5AW048 46,000 TDR 11.20 — 11.20 9.90
CC5A/CD5AW060 47,000 TDR 11.80 — 11.80 10.25
CK3BA060 46,500 TDR 11.20 — 11.20 10.20
CK5A/CK5BA060 46,000 TDR 11.20 — 11.20 10.20
CK5A/CK5BW048 46,000 TDR 11.20 — 11.20 9.95
CK5A/CK5BX060 47,000 TDR 11.80 — 11.80 10.45
060-E
CC5A/CD5AW060* 56,500 NONE 10.80 11.00 11.00 9.70
CC5A/CD5AA060 54,500 NONE 10.60 10.80 10.80 9.55
CE3AA060 56,500 NONE 10.80 11.00 11.00 9.80
CK5A/CK5BA060 54,500 NONE 10.60 10.80 10.80 9.55
CK5A/CK5BX060 56,500 NONE 10.80 11.00 11.00 9.70
F(A,B)4AN(F,B,C)060 57,000 TDR 10.80 — 10.80 9.40
FB4ANB070 57,500 TDR 11.00 — 11.00 9.80
FC4BNB070 57,500 TDR & TXV 11.00 — — 9.80
FC4BN(F,B)060 57,000 TDR & TXV 10.80 — — 9.40
FG3AAA060 56,000 NONE 10.80 11.00 11.00 9.65
FK4CNB006 57,500 TDR & TXV 12.00 — — 10.30
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CC5A/CD5AW060 56,500 TDR 11.80 — 11.80 10.30
CK5A/CK5BW060 56,500 TDR 11.80 — 11.80 10.30
