6. FRONT PANEL ASSLY
Reference Part Reference Part
Designator Description Designation Description
POT
VR1
5K, WWPOT VR3 500E, WWPOT
VR2 1K, WWPOT VR4 50E, WWPOT
SWITCH
SW1
16A/250V ON/OFF SWITCH
7. MAIN CHASSIS ASSLY
Reference Part
Designator Description
RESISTOR
R1
4.7K/2W, MOR
R2 0.025E / 25W SHUNT
DIODES
CR1
U30D40C (30AMP/400V DUAL DIODE)
CAPACITORS
C1
6 X 15,000µF, ELE
C2 1µF / 250V AC CAP X 2
RECTIFIER HEATSINK ASSLY
DIODES
CR1
40HFR20 CR3 40HF20
CR2 40HFR20 CR4 40HF20
SCR1 2906, 25A
SCR1 2906, 25A
FILTER 15A/20A, RFI FILTER
VARISTOR 130V OR 230V TYPE 20D 361
FAN1 12V / 24V INNOVATIVE ( HI COOL )
FAN2 12V / 24V INNOVATIVE ( HI COOL )
8. BACK TROUGH ASSLY
Reference Part
Designator Description
FUSE1 20AMP, TYPE F ( 115V ) 8 Amp TYPE T ( 230V ) ( 6.5mm X 32mm )
MAIN BOARD 3 PIN AMERICAN 12 AWG 3 CORE CABLE
REMOTE TERMINAL 4 WAY 10A TERMINAL BLOCK
