Fig. 3 -- roof curb details 551j j – Bryant 551J User Manual
Page 7
7
NOTES:
1. Roof curb accessory is shipped disassembled.
2. Insulated panels.
3. Dimensions in [
] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on
curb).
6. Service clearance: 4 ft on each side.
7.
Direction of airflow.
ROOF CURB
ACCESSORY
A
UNIT SIZE
CRRFCURB001A01
1’-2”
[356]
CRRFCURB002A01
2’-0”
[610]
551J*04-06
CONNECTOR
PKG. ACCY.
B
C
D ALT
DRAIN
HOLE
POWER
CONTROL
ACCESSORY
POWER
CRBTMPWR003A01
1’-9
11
/
16
”
[551]
1
3
/
4
”
[44.5]
1’-4”
[406]
CRBTMPWR004A01
3
/
4
” [19] NPT
1
1
/
4
” [31.7]
1
/
2
” [12.7]
NPT
1
/
2
” [12.7]
NPT
C10059
Fig. 3 -- Roof Curb Details
551J
j
