Appendix A
724-746-5500 | blackbox.com A-3
Character Regular Font Length Bold Font Length
BLOCK 07 = 4.67%
MAC ADDR 119 = 79.33%
IP MAC ADDR 140 = 93.33%
З 07 = 4.67% 10 = 6.67%
Д 07 = 4.67% 10 = 6.67%
Й 07 = 4.67% 10 = 6.67%
Ц 07 = 4.67% 10 = 6.67%
Ь 07 = 4.67% 10 = 6.67%
С 07 = 4.67% 10 = 6.67%
WEEK NO. 21 = 14.00% 30 = 20.00%
JULIAN DATE 21 = 14.00% 30 = 20.00%
4-DIGIT YEAR 28 = 18.60% 40 = 26.67%
NUM MONTH 14 = 9.33% 20 = 13.33%
The characters listed in the above table can be used to design a custom imprint for
Line 1 and/or Line 2.
1. The maximum displacement (print length) of the print head is 150 dots, or 1.4”
(36 mm).
2. To determine if your desired imprint exceeds the maximum number of dots, add
the lengths of each character from the table. The total should be less than 150
dots or 99%.
a. Regular font characters are seven dots high and five dots wide, with a length
of seven dots (5 dots for the character and 2 dots for the space) or 16 cpi.
b. Bold font characters are nine dots high and eight dots wide, with a length of
ten dots (8 dots for the character and 2 dots for the space) or 11 cpi.
Default NTP Time Servers
The following table lists the 18 predefined NTP time servers that are
preprogrammed in your Auto-Sync Time Clock.
