19
BUNN Espress™ Model ES•1A™
2 1 3
Figure Description Part Number
1 ...... Inlet water fitting ............................. 23609.0000
2 ...... Grommet liquid level probe ............. 23608.0000
3 ...... Terminal block ................................. 22814.0000
4 ...... Probe, liquid level ............................ 23607.0000
5 ...... Compression nut, level probe .......... 23629.0000
6 ...... Mounting nut, level probe ................ 23606.0000
7 ...... Probe assy. hex fitting ..................... 23605.0000
8 ...... Seal washer ..................................... 23628.0000
9 ...... Pressure pop-off valve .................... 22575.0000
10 .... Compensation valve ........................ 23603.0000
P-166
Figure Description Part Number
11 .... Flat washer ...................................... 24030.0001
12 .... Tank ................................................ 23647.0000
13 .... Drain plug, heat exchanger .............. 23602.0000
14 .... Drain plug, tank ............................... 23601.0000
15 .... Tank heater/Gasket kit ..................... 24274.1001
16 .... Flat washer ...................................... 24029.0000
17 .... Screw .............................................. 23934.0000
18 .... Tank heater terminal shorting bar .... 23598.0000
19 .... Limit thermostat (not illustrated) ..... 04680.0004
20 .... Band clamp (not illustrated) ............ 23468.0000
16 17 18
REPLACEMENT PARTS
