LTC 2210 Series | Instruction Manual | Unpacking
Bosch Security Systems | December 17, 2004
EN | 6
1.0 UNPACKING
This equipment should be unpacked and handled with
care. If an item appears to have been damaged in
shipment, notify the shipper.
Verify that all parts shown in the Parts List have been
included. If any items are missing, notify your Bosch
Security Systems Sales or Customer Service
Representative.
The original packing carton is the safest container in
which to transport the unit. Save it for possible future
use.
1.1 Parts List
2.0 SERVICE
If the unit needs repair, contact the nearest Bosch
Security Systems Service Center for authorization to
return and shipping instructions.
Service Centers
USA
Phone: 800-366-2283 or 717-735-6638
Fax: 800-366-1329 or 717-735-6639
CCTV Spare Parts
Phone: 800-894-5215 or 408-956-3853 or 3854
Fax: 408-957-3198
E-mail: [email protected]
Canada
Phone: 514-738-2434
Europe, Middle East & Asia Pacific Region
Phone: 32-1-440-0711
For additional information, see
www.boschsecurity.com.
3.0 DESCRIPTION
The LTC 2210 Series video motion detectors utilize
edge detection with digital tracing technology. Patented
circuitry provides reliable security surveillance
protection. These economical, full featured single
channel detectors provide flexible operation to
maximize performance and minimize false alarms.
Motion is detected over the full active video for NTSC,
PAL and SECAM.
4.0 INSTALLATION
4.1 Power
Model LTC2210/60 LTC 2210/50
Rated Voltage 120 VAC, 50/60 Hz 230 VAC, 50/60 Hz
Voltage Range 105 to 130 195.5 to 253
Power at rated voltage
5 W 5 W
4.2 Mounting
These motion detectors are supplied as desk top half-
rack units. For rack mounting, the LTC 9101/00 rack-
mount kit is available.
4.3 Video Looping Input
There are two smart BNC connectors on the rear
panel named IN and LOOP. The camera input should
be connected to IN while LOOP may be used as a
looping output. The camera input is automatically
terminated (nonlooping operation) or unterminated
(looping operation).
4.4 Monitor Output
The monitor output, named OUT, is designed for a
75 Ω load. Therefore if the monitor output cable is
looped through other accessories, ensure that the last
unit on the line has its termination set to 75 Ω
Qty Item
1 Unit (verify model number)
1 One (1) 15-pin cable assembly
