5.11 Display
The display menu is used to configure how the motion
detector looks on the monitor screen.
Display
>PREVIOUS MENU
DISPLAY ZONE OFF
BACKGROUND OUTLINED
ALL ACTIVITY OFF
OVERSCAN 05
Select: ENTER
Exit Menu:ESC Scroll: ↓
1. The LTC 2210 can detect motion over the full active
video signal, however all of this cannot be displayed
on the video monitor as most video monitors cannot
display the entire active video signal. This parameter
allows the video area where detection zones are
defined to be restricted so that the full detection area
can always be seen on the display monitor.
Changing the OVERSCAN setting reduces the
video area where zones are drawn.
2. An Overscan Setting of 05 (5%) will display the
complete detection area on most video monitors.
5.12 Language
Use the Language option on the main menu to change
the language. Press ENTER to select the required
language. All screens will now be displayed in the
selected language.
The options are: English, French, German, Spanish,
Dutch, and Italian.
5.13 Operation and Setup
Most programmable options are set to values that
should work without change for most applications. It is
normally only necessary to define the area where
motion should be detected. To do this press the
SETUP key to enter the programming. Select Zone
Setup followed by Define Zone. Define a Zone where
you wish to detect motion. Press ESC several times to
leave programming.
Item Settings Description
DisplayZone ON/OFF Switching this option on
displays the defined active
zones during operation.
This is useful when
programming and adjusting
the motion detector.
Background OUTLINED/
SOLID
This allows the menu
background to be changed
from a solid black
background to a
transparent background,
where the menu text is
fringed.
ALL
ACTIVITY
ON/OFF Switching this option ON
displays Motion Tracer dots
on the monitor screen for
all movement, even if it is
not sufficient to be
detected as motion.
OVERSCAN
00 Full Video, no reduction
05 2 Reduces video by 5%
10 Reduces video by 10%
20 Reduces video by 20%
