Selection Guide for Drills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Drills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Selection Guide for Sanders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Straight Grinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Angle Grinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Disc Sanders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
CONTE NTS.
DRILLS
GRINDERS
Selection Guide for Screwdrivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Shut-off Screwdriver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Impact Wrenches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Tappers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
SCREWDRIVERS AND TAPPERS
High-frequency technology correctly applied . . . . . . . . . . . . . . . . . . . .64
59- 62
ACCESSORIES
Balancers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Plug-in Connections and Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
HIGH-FREQUENCY TECHNOLOGY
All of the air tools listed in this
catalogue meet the following
standards or norm documents
EN 792, EN 50144, in accordance
with the regulations of Directives
89/392/EEC.
Conformity
Better performance through
higher frequency
Because their carbon brushes are
subject to wear, universal motors of
conventional power tools are unable
to satisfy these requirements. On the
other hand, the brushless asynchro-
nous motor is ideally suited.
The current frequency it is supplied
with determines its rotational speed,
which, in turn, determines the out-
put that can be achieved. A higher
frequency therefore means a higher
speed and a higher output.
High power at a constant
speed
In continuous operation at 300 Hz,
Bosch high-frequency tools have a
power output of up to 400 Watts
per kg machine weight. In the short
term, peak performances of up to
2.5 times this value are possible.
The speed remains almost constant
– irrespective of whether the tool is
being operated at idle or full load.
Unique
economy
A further argument in favour of
high-frequency tools: their econo-
my. Their efficiency and thus their
power consumption means that
they have unrivalled economy.
Their long service life and low
maintenance requirements and
power consumption offer an eco-
nomic solution for every type of
application.
Distinct environmental
consciousness
Environmental thinking plays a cen-
tral role in all Bosch products:
from the initial development of the
idea and energy saving products, to
environmentally friendly packaging
and disposal.
If a Bosch high-frequency tool is
irreparably damaged, Bosch will
take back the old tool. They are col-
lected centrally in the service centre
and passed on for careful recycling.
Special power saving
measures
Bosch is also innovative in the
area of power saving and places an
emphasis on future-oriented tech-
nology: The heat recovery system
in the Murrhard plant, for example,
produces savings of over half a mil-
lion litres of heating oil a year.
Information
from the Internet
Bosch now offers users and others
interested in industrial tools all cur-
rent product information on the
Internet. Here you will find a free
online catalogue illustrating in text
and pictures all the common cord-
less, air and high-frequency tools for
industrial use. More information on
Page 4.
H IG H-FR EQU E NCY POWE R TOOLS:
I N EXPE NSIVE POWE R APPLICATION.
In spite of increasing automation in industrial production, the use of hand-held tools has
advantages in many work operations. These tools must fulfil several requirements: robustness,
powerful and a long service life, but they must also be easy to manage with high operating
comfort.
Certified in
accordance
with ISO 9001
Certificate no. FM 30078
All weight data in this catalogue corres-
ponds to the EPTA Procedure 01/2003.
