23 22
Accessory Part number Comes complete with Remarks Switc
h
type Toolholding fixtureCollet c
huc
k (mm)
W
eight without
cabel (kg) Nominal current (A) Nominal power Output (W) Nominal power consumption (W) No load speed (rpm) Admissible grinding point-
l
(mm)
STRAIGHT GRINDERS.
The optimised straight grinders in
all power classes for the widest pos-
sible variety of applications
The ideal structural shape for ergo-
nomic work
Constant speed, even at extremely
high loads
Efficient work with longest possible
service life
Robust motors with long service
lives and low maintenance costs
Extremely favourable weight-perfor-
mance ratio
Order number Volt
age (V)
Frequency (Hz)
1 608 570 025
1 907 950 506
1 907 950 509
0 602 210 001 265 200 50
0 602 210 004 135 200 50
0 602 210 004 200 300 50
0 602 211 004 265 200 50
0 602 211 010 135 200 50
0 602 211 017 72 200 50
0 602 211 010 200 300 50
0 602 211 018 72 300 50
0 602 245 034 200 300 40
0 602 245 011 72 300 40
3100 600 440 1.6 2.5 6
3100 600 440 3.3 2.5 6
4700 900 630 3.3 2.5 6
Collet chuck l 6 mm
Open-ended spanner SW 12
Open-ended spanner SW 15
Post handle,
offsett drive for
polishing heads with
low circumference
velocity Toggle HGS 65/50
2 608 570 009
1 607 950 511
1 607 950 505
12 000 950 700 2.8 4.3 8
12 000 950 700 5.5 4.3 8
12 000 950 700 10.0 4.3 8
18 000 1450 1050 5.5 4.3 8
18 000 1450 1050 15.2 4.3 8
Collet chuck l 8 mm
Open-ended spanner SW 14
Open-ended spanner SW 22
Post handle,
central output dirve Toggle
3 607 950 004 18 000 1800 1500 6.4 4.7 Spindle M 14
18 000 1800 1500 17.7 4.7 Spindle M 14
Open-ended spanner SW 27 Post handle,
central output dirve
for grinding wheels
with internal thread Toggle
Lever switch with
lock
for grinding points
40 to 50 mm in diameter
The machines come equipped with a special 4-m-long cable without plug.
HGS 77/50
HGS 85/40
Your specialist dealer can provide you with information on the complete set of quality accessories.
