B&B Electronics Asynchronous to Synchronous Converter 2010 - Manual (Page 9)

2010AS3297 Manual 7
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 434-7094
APPENDIX A: SPECIFICATIONS
Data Rates: Up to 19.2 Kbps
Clocking: Provided by modem or multiplexer
Buffer: 4 bit RTS override feature empties buffers before dropping RTS,
making the Model 2010 usable in a polling environment
Data Transmission: Full or half duplex
Connectors:
Async.: DB-25 female
Sync.:
DB-25 male
Power: No external power required; uses power from data and control
signals
Temperature Range: 0-60°C (32-140°F)
Altitude: 0-15,000 feet
Humidity: Up to 95% non-condensing
Dimensions: 3.2" x 2.0” x 0.75"
Weight: 2 oz.
