KLT-E TRI-LEG TILTING KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KLT-20E (20 gallon), KLT-30E (30 gallon), KLT-40E (40 gallon), KLT-60E (60 gallon), KLT-80E (80 gallon) or KLT-100E (100 gallon) electrically heated tilting kettle
on legs. The unit shall have a double wall interior to form a steam jacket around the lower 2/3 of the kettle. The jacket enclosure shall contain distilled water which is factory sealed. The
bottom of the kettle shall be of hemispherical design for superior heat circulation. The console shall be drip proof, stainless steel clad and shall be supported on all welded, 1-5/8” (42mm)
diameter stainless steel frame and legs fitted with 4 hole adjustable flanged feet for securing to floor. The unit shall pivot on trunions connected to the tilt mechanism and the outbore
bearing connected to the frame and shall permit the kettle to tilt forward a full 90° for complete emptying. The tilt mechanism shall be self locking for positive stop action. Construction
shall be of all welded satin finish 304 stainless steel. The controls shall be integrally mounted and shall include a power switch, thermostat with range of 165-285°F (74-140°C), a cook
indicator light, pressure gauge, safety valve, low water light and low water shut off. The elements shall be removable. Unit shall be ASME code stamped and National Board registered.
Provide options and accessories as indicated.
Printed in U.S.A.
NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00015 Rev G (9/12)
POWER CONNECTION:
Refer to data plate.
MAXIMUM PRESSURE:
All models
50 PSI (345 kPa)
SHIPPING INFORMATION:
Approx. Weight:
KLT-20E
350 lbs. (159 kg)
KLT-30E
365 lbs. (166 kg)
KLT-40E
400 lbs. (181 kg)
KLT-60E
465 lbs. (211 kg)
KLT-80E
570 lbs. (259 kg)
KLT-100E
680 lbs. (308 kg)
MODEL
A
B
C
D
E
F
G
H
J (2”)
J (3”)
K (2”)
K (3”)
L
M
KLT-20E
21[533]
18[457]
38[965]
36[914]
15[381]
18[457]
14[356] 19.25[489] 14.75[375] 15.5[394]
18[457]
17.5[445]
-
63.5[1613]
KLT-30E
24[610]
20[508]
38[965]
39[990]
16.5[419]
19[483] 12.38[314] 19.25[489] 16.75[425] 17.25[438] 16[406]
15.5[394]
-
66.5[1689]
KLT-40E
26[660]
22.5[572]
38[965]
41[1041] 17.5[445]
23[584]
10254] 20.25[514] 17.5[445] 18.5[470] 13.5[343]
13[330]
-
68.5[1740]
KLT-60E 29.5[749]
26[660]
42[1067] 44.5[1130] 19.13[486] 24[610]
11[280] 22.25[565] 19.5[495] 20.75[527] 14[356]
13.5[343] 10.5[267] 76[1930]
KLT-80E
33[838]
28[711]
45[1143] 48[1219] 20.88[530] 27[686]
12.6[321] 23.75[603] 20.25[514] 21.25[540] 15[381]
14.5[368]
12[305] 82.5[2096]
KLT-100E 35.5[902] 29.75[755] 48.75[1238] 49.5[1257] 22.25[565] 32[813]
14.5[368] 25.25[641] 20.25[514] 21.25[540] 18.75[476] 18.25[464] 14[356] 88.5[2248]
AVAILABLE kW
MODEL
STD
OPT
KLT-20E
12
N/A
KLT-30E
15
N/A
KLT-40E
18
24
KLT-60E
18
24, 33
KLT-80E
18
24, 33
KLT-100E
24
33
AMPS PER LINE
KW PHASE
208V
220V
240V
380V
415V
480V
600V
12
1
57.7
54.4
50.0
N/A
N/A
N/A
N/A
3
33.3
31.5
28.9
18.2
16.7
14.4
11.6
15
1
72.1
68.2
62.5
N/A
N/A
N/A
N/A
3
41.6
39.4
36.1
22.8
20.9
18.0
14.5
18
1
86.5
81.8
75.0
N/A
N/A
N/A
N/A
3
50.0
47.2
43.3
27.3
25.0
21.7
21.7
24
3
66.6
63.0
57.7
36.5
33.4
28.9
23.1
33
3
91.6
86.6
79.4
50.1
45.9
39.7
31.8
