LR 1250
21
Lift chart - fixed jib
(No. 1008.xx)
Offset 15°
Capacities in metric tonnes with fixed jib (No. 1008.xx), 82.3 counterweight + 36 t carbody counterweight. Above lift chart is for reference only.
For actual lift duty and complete chart with all available configurations please refer to lift chart in operator‘s cab or manual.
Main boom 20 m
Main boom 29 m
Main boom 38 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
9
35.9
35.5
11
35.9
34.0
28.9
12
35.9
33.2
27.7
19.8
14
35.9
31.5
25.5
18.3
16
35.1
29.9
23.9
17.1
20
32.8
26.5
20.0
15.1
24
27.5
23.2
17.0
13.4
28
24.0
20.7
14.8
11.7
30
23.0
19.5
13.8
11.1
32
18.4
13.0
10.5
38
11.3
9.0
44
7.9
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
8
35.9
35.9
10
35.9
35.2
30.2
12
35.9
34.2
28.5
19.7
16
35.9
32.0
25.0
17.3
20
34.7
29.9
21.9
15.4
28
27.6
24.6
17.1
13.0
32
23.0
21.8
15.3
11.6
36
19.3
19.7
13.7
10.6
38
17.8
18.2
13.2
10.1
40
16.8
12.7
9.7
46
11.4
8.7
50
8.1
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
6.3
35.9
8
35.9
35.8
10
35.9
35.2
29.4
13
35.9
33.6
26.8
18.9
16
35.9
32.3
24.7
17.3
20
35.9
30.3
22.6
15.6
28
27.0
26.2
18.6
13.5
36
18.7
19.0
15.1
11.5
46
12.5
12.8
12.5
9.5
48
11.9
12.1
9.2
55
9.7
8.4
60
7.9
Main boom 47 m
Main boom 56 m
Main boom 62 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
6.6
35.9
8
35.9
35.8
11
35.9
34.5
28.3
13
35.9
33.7
26.9
18.5
16
35.9
32.6
25.1
17.1
20
34.8
31.1
22.9
15.7
28
26.4
26.8
19.8
13.7
36
18.1
18.4
16.8
12.3
50
10.2
10.5
11.0
9.7
55
8.7
9.1
9.0
60
7.6
8.0
65
6.7
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
6.9
35.9
9
35.9
34.5
11
35.9
33.7
26.6
13
35.9
32.8
25.5
17.8
20
34.3
29.9
22.0
15.5
28
25.4
25.6
19.5
13.7
36
17.4
17.8
17.3
12.7
44
12.3
12.6
13.1
11.2
55
7.8
8.0
8.5
8.9
60
6.2
6.5
7.0
7.4
70
4.5
4.9
75
3.9
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.1
35.9
9
35.9
33.9
11
35.9
33.2
25.5
13
35.9
32.4
24.7
17.3
20
32.7
28.9
21.6
15.2
28
24.3
24.5
19.3
13.6
36
17.0
17.3
17.7
12.6
44
11.8
12.1
12.7
11.5
55
7.3
7.6
8.1
8.5
65
4.5
4.8
5.2
5.6
75
3.1
3.5
80
2.6
Main boom 68 m
Main boom 71 m
Main boom 74 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.3
35.9
9
35.9
32.8
11
35.8
32.3
24.3
14
34.9
30.9
23.2
16.7
20
31.1
27.8
20.9
14.9
28
23.4
23.5
18.8
13.4
36
16.3
16.5
16.9
12.5
44
11.4
11.7
12.3
11.7
55
6.9
7.1
7.6
8.1
70
3.0
3.2
3.7
4.1
75
2.3
2.7
3.1
80
2.2
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.4
35.8
9
35.2
32.2
11
33.9
31.0
24.0
14
32.6
29.4
22.8
16.3
16
31.9
28.7
21.9
15.8
20
29.3
26.9
20.7
14.6
28
22.9
23.1
18.7
13.3
36
15.9
16.1
16.5
12.4
44
11.2
11.5
11.9
11.6
55
6.6
6.9
7.4
7.9
65
3.9
4.1
4.6
5.0
75
2.0
2.5
2.9
Fixed jib length in (m)
Radius
11
14
17
(m)
t
t
t
7.6
35.1
9
34.3
31.1
10
32.8
30.8
27.8
12
31.2
28.3
26.7
16
30.1
26.9
24.4
20
27.8
25.5
23.4
28
22.4
22.3
21.1
36
15.5
15.7
15.9
44
10.9
11.1
11.3
55
6.4
6.6
6.9
70
2.5
2.8
3.0
75
2.0
