Lift chart - luffing jib
(No. 1916.xx)
Main boom 45°
Main boom 23 m Main boom 35 m
Jib length in (m)
20 29 41 53 62 71 83
Radius (m) t t t t t t t
35.4 18.9
38 17.2
44 13.9
46 13.1
55 9.9
65 7.2
70 6.3 5.9
75 5.2
80 4.1
85 3.6
90 2.5
95 2.1
Jib length in (m)
20 29 41 53 62
Radius (m) t t t t t
43.8 11.9
46 11.2
55 8.3
65 5.9
75 4.0
80 3.0
85 2.6
Main boom 44 m Main boom 53 m
Jib length in (m)
20 29 41 53
Radius (m) t t t t
50.2 8.0
60 5.7
70 3.7
80 2.1
Jib length in (m)
20 29
Radius (m) t t
56.6 4.9
65 3.3
Main boom 56 m Main boom 59 m
Jib length in (m)
20 29
Radius (m) t t
58.7 3.9
60 3.8
70 2.1
Jib length in (m)
20
Radius (m) t
60.8 2.9
Capacities in metric tonnes with luffing jib (No. 1916.xx), 82.3 counterweight + 36 t carbody counterweight. Above lift chart is for reference only.
For actual lift duty and complete chart with all available configurations please refer to lift chart in operator‘s cab or manual.
