R 954 C Litronic Machine for Industrial Applications
TechnicalData
Undercarriage
Versions
HD-W
�������������������������
special duty, wide gauge
EW
�����������������������������
heavy duty, very wide gauge
S-EW
��������������������������
removable side frames, extra wide gauge
S-EW HD
���������������������
heavy duty, removable side frames, extra wide
gauge
Drive
��������������������������������
Liebherr swash plate motors with integrated
brake valves on both sides
Transmission
����������������������
Liebherr planetary reduction gears
Travel speed
����������������������
HD-W:
low range – 3.3 km/h
high range – 4,8 km/h
EW:
low range – 2.6 km/h
high range – 3.6 km/h
S-EW:
low range – 3.0 km/h
high range – 4.8 km/h
S-EW HD: low range – 2.6 km/h
high range – 3.6 km/h
Drawbar pull max.
����������������
HD-W: 429 kN
S-EW:
478 kN
EW:
553 kN
S-EW HD: 553 kN
Track components
���������������
HD-W/S-EW: D 7 G, maintenance-free
EW/S-EW HD: D 8 K, maintenance-free
Track rollers/Carrier rollers
�����
HD-W: 10/2
S-EW:
13/3
EW:
9/2
S-EW HD: 13/3
Tracks
������������������������������
sealed and greased
Track pads
�������������������������
HD-W/S-EW: triple grouser
EW:
double grouser
S-EW HD:
flat pad
Digging locks
����������������������
wet multi-discs (spring applied, pressure relea-
sed)
Brake valves
�����������������������
integrated into travel motor
Attachment
Type
��������������������������������
high-strength steel plates at highly-stressed
points for the toughest requirements. Complex
and stable mountings of attachment and cylin-
ders. Unrivalled strength, even at high loads
Hydraulic cylinders
���������������
Liebherr cylinders with special seal system.
Shock absorption
Pivots
������������������������������
sealed, low maintenance
Lubrication
�������������������������
Liebherr semi-automatic central lubrication
system
Engine
Rating per ISO 9249
�������������
240 kW (326 HP) at 1,800 RPM
Model
�������������������������������
Liebherr D 936 L
Type
��������������������������������
6 cylinder in-line
Bore/Stroke
������������������
122/150 mm
Displacement
����������������
10.5 l
Engine operation
�����������������
4-stroke diesel
unit pump system
turbo-charged and after-cooled
Cooling
�����������������������������
water-cooled and integrated motor oil cooler
Air cleaner
�������������������������
dry-type air cleaner with pre-cleaner, primary and
safety elements, automatic dust discharge
Fuel tank
���������������������������
700 l
Standard
���������������������������
sensor controlled engine idling
Electrical system
Voltage
�����������������������
24 V
Batteries
����������������������
2 x 170 Ah/12 V
Starter
������������������������
24 V/7.8 kW
Alternator
���������������������
three phase current 28 V/80 A
HydraulicSystem
Hydraulic pump
for attachment and
travel drive
�������������������
two Liebherr variable flow, swash plate pumps
Max. flow
���������������������
2 x 350 l/min.
Max. pressure
���������������
350 bar
Pump regulation
������������������
electro-hydraulic with electronic engine speed
sensing regulation, pressure compensation, flow
compensation, automatic oil flow optimizer
Hydraulic pump
for swing drive
��������������
reversible, variable flow, swash plate pump,
closed-loop circuit
Max. flow
���������������������
211 l/min.
Max. pressure
���������������
384 bar
Hydraulic tank
��������������������
440 l
Hydraulic system
�����������������
790 l
Hydraulic oil filter
�����������������
2 full flow filters in return line with inte grated fine
filter area (5 µm)
Hydraulic oil cooler
���������������
cooler unit, consisting of radiator for engine
coolant with after-cooler core, sandwiched with
cooler for hydraulic fluid and fuel with hydro-
statically controlled fan drives
MODE selection
������������������
adjustment of machine performance and the
hydraulics via a mode selector to match applica-
tion
ECO
���������������������������
for especially economical and environ mentally
friendly operation
POWER
�����������������������
for maximum digging power and heavy duty jobs
LIFT
���������������������������
for lifting
FINE
��������������������������
for precision work and lifting through very sensi-
tive movements
RPM adjustment
�����������������
stepless adjustment of engine output via the rpm
at each selected mode
HydraulicControls
Power distribution
����������������
via control valves in single block with integrated
safety valves
Flow summation
������������
to boom and stick
Closed-loop circuit
���������
for uppercarriage swing drive
Servo circuit
Attachment and swing
�����
proportional via joystick levers
Travel
�������������������������
proportional via foot pedal
Additional functions
��������������
via foot pedals or joystick push buttons
SwingDrive
Drive by
����������������������������
Liebherr swash plate motor with integrated brake
valves
Transmission
����������������������
Liebherr compact planetary reduction gear
Swing ring
�������������������������
Liebherr, sealed single race ball bearing swing
ring, internal teeth
Swing speed
����������������������
0 – 6.0 RPM stepless
Swing torque
����������������������
154 kNm
Holding brake
���������������������
wet multi-disc (spring applied, pressure released)
Option
������������������������������
pedal controlled positioning brake
Operator’sCab
Cab
���������������������������������
resiliently mounted, sound insulated, tinted
windows, front window stores overhead, door
with sliding window
Operator’s seat
�������������������
fully adjustable, shockabsorbing suspen sion,
adjustable to operator’s weight and size, 6-way
adjustable Liebherr seat
Joysticks
���������������������������
integrated into adjustable consoles
Monitoring
�������������������������
menu driven query of current operating condi-
tions via the LCD display. Automatic monitoring,
display, warning (acoustical and optical signal)
and saving machine data, for example, engine
overheating, low engine oil pressure or low
hydraulic oil level
Air conditioning
�������������������
standard air conditioning, combined cooler/
heater, additional dust filter in fresh air/recircu-
lated
Noise emission
ISO 6396
���������������������������
L
pA
(inside cab)
= 77 dB(A)
2000/14/EC
������������������������
L
WA
(surround noise) = 105 dB(A)
