Shells for loose material, Eb a c d – Liebherr LH 120 M High Rise Litronic User Manual
Page 23
23
Capacity
m
3
A
mm
B
mm
C
mm
D
mm
E
mm
Weight
kg
GMZ 50 (excavator class: 35 - 120 t)
Clamshell*
* Light material grapple (max. 1,1 t/m³)
The list does not represent the complete grapple range. Additional dimensions on request.
A: Element width, B: Span width of grapple, open, C: Height of grapple, open, D: Heigt of grapple, closed, E: Span width of grapple, closed
E
B
A
C
D
Shells for loose Material
3.5
1,400
3,380
1,715
2,120
3,230
2,670
4
1,600
3,380
1,715
2,120
3,230
2,800
4.5
1,800
3,380
1,715
2,120
3,230
2,930
5
2,000
3,380
1,715
2,120
3,230
3,060
5.5
2,200
3,380
1,715
2,120
3,230
3,190
6
2,400
3,380
1,715
2,120
3,230
3,320
Capacity
m
3
A
mm
B
mm
C
mm
D
mm
E
mm
Weight
kg
GMZ 50 (excavator class: 35 - 120 t)
Clamshell*
3.5
1,400
3,380
1,715
2,120
3,230
2,670
4
1,600
3,380
1,715
2,120
3,230
2,800
4.5
1,800
3,380
1,715
2,120
3,230
2,930
5
2,000
3,380
1,715
2,120
3,230
3,060
5.5
2,200
3,380
1,715
2,120
3,230
3,190
6
2,400
3,380
1,715
2,120
3,230
3,320
