Liebherr LH 120 M High Rise Litronic - Manual (Page 22)

22
Capacity
m 3
A
mm
B
mm
C
mm
D
mm
E
mm
Weight
kg
GM 10B (excavator class: 18 - 30 t)
Digging shell
Clamshell
GM 20B (excavator class: 20 - 47 t)
Digging shell
Clamshell
GM 22C (excavator class: 47 - 71 t)
Digging shell
Clamshell
GM 25B (excavator class: 71 - 100 t)
Digging shell
Clamshell
The list does not represent the complete grapple range. Additional dimensions on request.
A: Element width, B: Span width of grapple, open, C: Height of grapple, open, D: Heigt of grapple, closed, E: Span width of grapple, closed
Shells for loose Material
0.17 320 1,645 1,540 1,970 1,440 765
0.22 400 1,645 1,540 1,970 1,440 805
0.25 450 1,645 1,540 1,970 1,440 820
0.35 600 1,645 1,540 1,970 1,440 860
0.45 800 1,645 1,540 1,970 1,440 915
0.6 1,000 1,645 1,540 1,970 1,440 970
0.7 900 1,645 1,540 1,970 1,440 1,195
1 1,000 1,980 1,445 2,125 1,830 1,040
1.3 1,300 1,980 1,445 2,125 1,830 1,120
1.5 1,500 1,980 1,445 2,125 1,830 1,180
1.8 1,800 1,980 1,445 2,125 1,830 1,425
0.45 600 1,955 1,920 2,420 1,650 1,160
0.6 800 1,955 1,920 2,420 1,650 1,210
0.,75 1,000 1,955 1,920 2,420 1,650 1,285
0.9 1,200 1,955 1,920 2,420 1,650 1,350
1.3 1,000 2,250 1,825 2,560 2,090 1,355
1.5 1,200 2,250 1,825 2,560 2,090 1,415
2 1,600 2,250 1,825 2,560 2,090 1,550
2.5 2,000 2,215 1,825 2,555 2,090 1,820
1.4 1,150 2,555 2,910 3,035 2,240 2,100
1.6 1,300 2,555 2,910 3,035 2,240 2,250
1.6 1,300 2,355 2,255 2,895 2,235 2,250
1.85 1,500 2,355 2,255 2,895 2,235 2,300
2 1,500 2,405 2,260 2,920 2,320 2,350
2.2 1,500 2,515 2,270 2,975 2,410 2,400
2.5 2,000 2,355 2,255 2,895 2,235 2,550
3 2,000 2,645 2,285 3,030 2,510 3,050
3.5 2,000 2,805 2,305 3,110 2,655 3,150
1.8 1,300 2,860 2,810 3,335 2,380 2,900
2 1,500 2,860 2,810 3,335 2,380 3,000
2.3 1,700 2,815 2,740 3,310 2,405 3,250
2.3 1,700 2,600 2,490 3,195 2,405 3,200
2.8 1,700 2,875 2,520 2,330 2,500 3,250
3 2,000 2,690 2,495 3,210 2,590 3,550
3.5 1,800 3,000 2,540 3,395 2,600 3,300
4 2,000 2,945 2,525 3,335 2,860 3,550
4.5 2,200 2,985 2,530 3,375 2,895 3,750
Capacity
m 3
A
mm
B
mm
C
mm
D
mm
E
mm
Weight
kg
GM 10B (excavator class: 18 - 30 t)
Digging shell
0.17 320 1,645 1,540 1,970 1,440 765
0.22 400 1,645 1,540 1,970 1,440 805
0.25 450 1,645 1,540 1,970 1,440 820
0.35 600 1,645 1,540 1,970 1,440 860
0.45 800 1,645 1,540 1,970 1,440 915
0.6 1,000 1,645 1,540 1,970 1,440 970
0.7 900 1,645 1,540 1,970 1,440 1,195
Clamshell
1 1,000 1,980 1,445 2,125 1,830 1,040
1.3 1,300 1,980 1,445 2,125 1,830 1,120
1.5 1,500 1,980 1,445 2,125 1,830 1,180
1.8 1,800 1,980 1,445 2,125 1,830 1,425
GM 20B (excavator class: 20 - 47 t)
Digging shell
0.45 600 1,955 1,920 2,420 1,650 1,160
0.6 800 1,955 1,920 2,420 1,650 1,210
0.,75 1,000 1,955 1,920 2,420 1,650 1,285
0.9 1,200 1,955 1,920 2,420 1,650 1,350
Clamshell
1.3 1,000 2,250 1,825 2,560 2,090 1,355
1.5 1,200 2,250 1,825 2,560 2,090 1,415
2 1,600 2,250 1,825 2,560 2,090 1,550
2.5 2,000 2,215 1,825 2,555 2,090 1,820
GM 22C (excavator class: 47 - 71 t)
Digging shell
1.4 1,150 2,555 2,910 3,035 2,240 2,100
1.6 1,300 2,555 2,910 3,035 2,240 2,250
Clamshell
1.6 1,300 2,355 2,255 2,895 2,235 2,250
1.85 1,500 2,355 2,255 2,895 2,235 2,300
2 1,500 2,405 2,260 2,920 2,320 2,350
2.2 1,500 2,515 2,270 2,975 2,410 2,400
2.5 2,000 2,355 2,255 2,895 2,235 2,550
3 2,000 2,645 2,285 3,030 2,510 3,050
3.5 2,000 2,805 2,305 3,110 2,655 3,150
GM 25B (excavator class: 71 - 100 t)
Digging shell
1.8 1,300 2,860 2,810 3,335 2,380 2,900
2 1,500 2,860 2,810 3,335 2,380 3,000
2.3 1,700 2,815 2,740 3,310 2,405 3,250
Clamshell
2.3 1,700 2,600 2,490 3,195 2,405 3,200
2.8 1,700 2,875 2,520 2,330 2,500 3,250
3 2,000 2,690 2,495 3,210 2,590 3,550
3.5 1,800 3,000 2,540 3,395 2,600 3,300
4 2,000 2,945 2,525 3,335 2,860 3,550
4.5 2,200 2,985 2,530 3,375 2,895 3,750
